Side 1/4

If you discover any missing components or damage call

1-800-465-7300 between 8:00 am and 3:30 pm eastern time

Monday to Friday

Read and save these instructions

IMPORTANT SAFEGUARDS

• IMPORTANT: Disconnect the power before cleaning,

servicing or performing routine maintenance.

If you are replacing an existing product, ensure

the power is disconnected before beginning this

installation.

Do not mount over tub or in shower stall

enclosure.

Not for use in kitchens.

• WARNING: To reduce the risk of fire or electric shock or

injury to persons observe the following:

Use this unit only in the manner intended by the

manufacturer. If you have questions, contact the

manufacturer.

Before servicing or cleaning the unit, switch

power off at the service panel and lock service

panel to prevent power from being switched on

accidentally. When the service disconnecting

means cannot be locked securely, fasten a

prominent warning device, such as a tag to the

service panel.

Installation work and electrical wiring must be done

by qualified person(s) in accordance with all

applicable codes and standards, including fire-rated

construction.

When cutting or drilling into wall or ceiling, do

not damage electrical wiring or other hidden

utilities.

Ducted fans must always be vented to the

outdoors.

Do not install this fan in a ceiling thermally

insulated to a value greater than R-40.

NEVER place a switch where it can be reached

from a shower or tub.

Sufficient air is needed for proper combustion and

exhausting of gases through the flue (chimney) of

fuel burning equipment to prevent back drafting.

Follow the heating equipment manufacturer’s

guidelines and safety standards such as those

published by National Fire Protection Association

(NFPA), and the American Society for Heating,

Refrigeration and Air Conditioning Engineers

(ASHRAE), and local code authorities.

Do not use this fan with any solid-state speed

control device.

• CAUTION: For general ventilating use only. Do not use

to exhaust hazardous or explosive materials and

vapors.

Before beginning the installation, remove from the carton

the packaged grill and light lens, the heater’s housing and

mounting brackets and any loose packaging. Remove any

tape which may be holding the exhaust fan’s damper

closed. Remove the heater’s wiring compartment cover.

Remove the light reflector from the heater housing – it is

secured in place by a screw. Place grill, lens, heater’s wire

compartment cover and light reflector back in the carton

until needed so they do not get damaged.

Mounting the Housing: New Construction

Using the Hanging Brackets

1. Insert the hanger bars in the slots provided in the

housing.

2. Locate the heater housing between joists so that the

bottom of the heater will be flush with the finished ceiling.

3. Use screws or nails to secure the hanger bars to the

ceiling joists.

4. Remove the desired electrical knockout from the junction

box in the housing.

Using Side Mounting Tabs

1. Locate the heater housing next to a ceiling joist.

2. Use screws through the keyhole slots in the mounting

tabs to loosely position the housing in place.

3. Adjust the height of the heater so that the housing will

be flush with the finished ceiling. When the housing is

properly positioned, secure in place using screws or nails.

4. Remove the desired electrical knockout from the junction

box in the housing.

Mounting the Housing: Existing Construction

1. Determine the desired location for the heater.

2. Drill a small hole through the ceiling at the chosen

location. Stick the end of a coat hanger through the hole

AIR KING LIMITED, 110 GLIDDEN ROAD, BRAMPTON, ONTARIO, CANADA; TEL. 905-456-2033, 1-800-465-7300, FAX. 905-456-1015

INSTALLATION

INSTRUCTIONS

Models AK965L & AK965FL

Heat/Vent/Light/Night Light

Fig 1.
