Quick Setup Guide

Declaration of Conformity

We, Manufacturer/Importer

Declare that the product

SOHO Live Series Switch

Live-16GT, Live-16GTM, Live-24GT

is in conformity with

In accordance with 2014/30/EU and 2014/35/EU Directive

Clause

Manufacturer/Importer

AirLive Technology Corporation

4F, No.132, Lane 235, Baoqian Rd., Xindian Dist.,

New Taipei City 23145, Taiwan

■

CE marking

Name : A van Rossem Position/ Title : Product Manager

Date : October 2023Place : Taiwan

AirLive Technology Co ion drporat eclares tha hi evt t s d ice

is in compliance with the ntesse ial require tsmen and

oth l ter re evan provis sion of i / direct ve 2014 30/EU, 2014/35/EU

■

EN IEC 61000-3-2:2019+A1:2021

■

EN 55032:2015+A11:2020

■

EN 55035:2017+A11:2020

■

EN 61000-3-3:2013+A2:2021+AC:2022-01

(EMC)

■

EN IEC 62368-1:2020/A11:2020

(LVD)

Conformity with

In accordance with RoHS Directive 2011/65/EU Annex II amending

Annex (EU)2015/863 and amending Annex (EU)2017/2102

Live -16GTM, Live-16GT, Live-24GT

Live Gigabit Switch

10/100/1000Mbps

LED DEF INIT NSIO

Power

Link/Act

Green ON

Green OFF

Green ON

Power is on and normal.

The switch is not receiving power.

Link connected.

Green OFF Link disconnect

Installation Step:

1. Remove the switch and accessories from the package.

2. Connect power to the switch. Make sure that “Power” LED is on.

3. Check the Port LED indicator status. When a device is connected

the port will light up.

4. For more product information visit www.airlive.com.

Live-16GT

DIP Switch Control:

1. Standard: Normal mode, all ports can communicate with each other.

2. Port Isolation/VLAN: Port Isolation mode,

In this mode ports 1~14 (16GT/GTM), 1~22 (24GT) cannot communicate

with each other and can only communicate with the UP-Link

ports 15/16 (16GT/GTM), 23/24 (24GT)

3. Network Clone: The Flow control function of all ports is disabled,

which is suitable for some environments that use broadcast or multicast

to transmit data.

Live Gigabit Switch

10/100/1000Mbps

Network Clone

24x 10/100/1000Mbps RJ45

Live-24GT

DIP Switch Control

Power

Installation Steps

Figure A

PWR

SYS

Link

ACT

Link/ACT

ACT

Link

PoE/ACT

1 3 5 7 9 11 13 15 17 19 21 23 25 27

2 4 6 8 10 12 14 16 18 20 22 24 26 28

Console

Reset

1 3 5

10 12 14 16

17 19 21

18 20

22 24

26 28 25 26 27 28

Combo

SYS

PWR

POE/ACT

Link/ACT

1 3 5 7 9 11 13 15 17 19 21 23 25 27

2 4 6 8 0 12 14 16 18 20 22 24 26 28

Link

ACT

Link

ACT

Reset

Console

1 3 5 7

2 4 6 8

9 11 13 15

10 12 14 16 26 28 25 26 27 28

17 19 21 23

18 20 22 24

25 27

Combo

1. Fix the L-shaped mounting brackets on both sides of the switch with the

screws provided in the accessories.

2. The mounting brackets are fixed on the guide groove with screws

to ensure that the switch is stable and horizontally installed on the rack.

Rack Installation for Live-16GT and Live-24GT:

16x 10/100/1000Mbps RJ45

Live-16GTM

16x 10/100/1000Mbps RJ45

Live -16GTM, Live-16GT, Live-24GT
