Side 1/21

USER MANUAL

ACR- 3888

+$6=1È/$7,.e=,.g1<9

,16758.&-$2%6à8*,

UŽIVATELSKÁ PŘÍRUČKA

U ŽÍVATEĽSKÁ PRÍRUČKA

BEDIENUGANLEITUNG

INSTRUCTION MANUAL

MA NUAL DE I NTRUCTIUNI

ȅǻǾīǿǼȈȁǼǿȉȅȊȇīǿǹȈ

НАРЪЧНИК ИЗПОЛЗВАНЕ ЗА

Overview of the Components

1. buttonPROJECTION

2. buttonON/OFF

3. buttonFM/USB

4. buttonTIME/SET/ M+

5. SNOOZE SLEEP/ /

DISPLAY HIGH/LOW/OFF

PAUSE/PLAY button

6. buttonHOUR/TU- / PREV

7. buttonMIN/TU+/ NEXT

8. buttonAL1/VOL-

9. buttonAL2/VOL+

10. PROJECTION RING (for angle adjustment)

11. PROJECTOR

12. LED display

13. playback portUSB

14. USB OUT CHARGE charging socket-

Back side

15. Battery compartment (power reserve)

16. DC 5V power supply connection

17. Focus control

18. Speaker

19. Dipole antenna

First Use of the Device /Introduction

•Select a proper place for the device. A dry, level and slip proof surface is suitable.

•Make sure the device is vented sufficiently!

•In all modes, the display automatically switches to the time display after about 10 seconds.

Power supply

1. Make sure the grid voltage corresponds to the figures on the rating plate.

2. Plug the power supply unit into a properly installed protective contact socket.

3. Connect the device with the power supply unit by plugging the jack of the power supply unit into the “DC 5V” jack.

Caution:

•This device should only be used with the mains supply unit (included). Do not use it for other devices.

•Only use a 5V power supply unit ( ). A different supply unit may damage the device.

Note

•Disconnect from mains power supply during longer periods of non-use.

•If you did not insert another reserve battery, the time and the station memory will be lost as soon as the power supply

is interrupted.

•

Inserting the reserve batteries

(Batteries are not included in the scope of delivery)

In case of power failure or if the power supply unit is pulled from the plug, the settings are maintained if the reserve batteries are

inserted.

1. battery on bottomOpen the compartment the side.

2. he polarity battery compartment).Insert ttwo type AAA/R031.5Vbatteries. Check that is correct (see

3. batteryClose the compartment.

Warning:

The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. Danger of explosion!

CAUTION:

•Batteries can leak battery acid. If the device is out of use for a long period of time, remove the batteries.

•Different battery types or new and used batteries must not be used together.

•Batteries are not to be disposed of together with domestic wastes. Dispose of the used batteries at the relevant

collection bin or at your dealer’s.

USB OUT CHARGE Charging Socket-

You can charge your Smart phone through this jack. Use the USB cable of your Smart phone for the connection.

Note:

•Due to the different Smart phone types that are offered today, and their different charging capacities, the loading

duration is dependent on the Smart phone used and its operating condition.

•A playback of audio-files through this connector is not possible.

USB playback port

This device has been developed in line with the latest technical advances in the USB field. The wide range of different USB

storage devices of all types allow us to guarantee full comwhich are currently on the market, unfortunately do not patibility with

all USB storage devices. For this reason, in rare cases there may be problems in playing back files from USB storage devices.

This is not a malfunction of the device.

General Operation

Switch device on/off

•You can toggle the device between standby and radio mode with the ON/OFF button.

•To disconnect the unit completely from the mains, pull the mains plug from the socket.

Volume

By pressing the AL1/VOL− / AL2/VOL+ buttons you can adjust the desired volume.

FM/USB button

Press the FM/USB button until the desired operating mode is shown on the display.

Display Brightness

In time display mode, u IGH/LOW/OFF button to adjust the display brightness. Select from: Light, dark and se the DISPLAY/H

off.

Setting the time (in standby)

1. button pressedKeep / the TIME SET/M+ a for short time. The time indicator begins to flash.

2. hours button heSet the – with the HOUR/TU tand minutes with the MIN/TU+ button.

NOTE:

If you do not press a button within 4 seconds, the settings are automatically accepted.

SNOOZE/SLEEP button (Delayed switch-off)

When the device is switched on, you can set the time after which the device will turn into standby mode; set the time in 10

minutes’ intervals from 90 to 10 minutes. The device will turn off automatically after the preset time.

1. button notification “90”Press SNOOZE/SLEEP the . for 2 seconds The dwill appear in the isplay.

2. utton of 10. “OFF”Press bthe repeatedly to reduce the time in steps The setting deactivates the function.

NOTE:

•To call up the still remaining time, press the button briefly.

•When activated the dot in the display next to “SLEEP” is illuminated.

Radio Mode

1. uncoilFully the wire antenna.

2. hts up on the display next toPress FM/USB button. A dot lig FM (frequency modulation)

3. Search for radio stations:

Briefly press the MIN/TU+ / HOUR/TU– buttons, until you have found the radio station which you are looking for. Preset

station: Keep the TIME SET/M+ button pressed for approx. 3 seconds. Select a preset location with the buttons MIN/TU+ /

HOUR/TU–. Preset the TIME SET/M+ button one more. The station is prese t.

NOTE:

•If the reception is too weak and there is interference on the received station, try to improve the reception by altering the

position and uncoiling or coiling the antenna.

Select the preset radio station

While in radio operation, repeatedly press the TIME/ . SET/M+ button or press the buttons MIN/TU+ / HOUR/TU- One preset

location after the other will be called up.

Projection

You can use this unit to project the time onto a wall or the ceiling.

•You can switch this function on and off with the PROJECTION button

•Swivel the PROJECTOR to the desired position.

•The back side of the projector has the FOCUS setting wheel with which you can adjust the sharpness of the projection.

USB Playback Mode

1. Pres Select USBs FM/USB button. function and “ ” will appear on the LED display.USB

2. Insert USB into USB playback port and music will begin to play.

3. Press PREV button to backward to last the song.

4. Press the NEXT button to forward to next song.

5. Press PAUSE button to pause the song.

Alarm Function

EN 1 EN 2

Produkt Specifikationer

Mærke:	AKAI
Kategori:	Ur
Model:	ACR-3888
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	215 mm
Dybde:	80 mm
Højde:	95 mm
Produktfarve:	Sort
Batterispænding:	1.5 V
Indbygget skærm:	Ja
Skærmtype:	LED
Skærm diagonal:	1.2 "
Tuner type:	Digital
Udgangseffekt (RMS):	- W
Antal USB 2.0-porte:	2
Strømkilde:	DC/batteri
USB-tilslutning:	Ja
Batteritype:	AAA
Antal understøttede batterier:	2
Understøttede radiobånd:	AM, FM, PLL
MP3-afspilning:	Ja
DC indgangsspænding:	3 V
Radiotype:	Ur
Antal forudindstillede stationer:	10
USB-opladningsport:	Ja
PLL-synthesizer:	Ja
Projektering:	Ja
