AS01K
ISSUED: OCT. 2014
Video Wall Stand and Accessories
INSTALLATION MANUAL
CAUT ION: DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
AS01346FP
55"
MAX 5
5
5
50
0
0
0k
k
k
kg
g
g
gx
x
x
x3
3
3
3
(
(
(
(11
11
11
110
0
0
0l
l
l
lb
b
b
bs
s
s
sx3
x3
x3
x3)
)
)
)
R
R
R
RATE
ATE
ATE
ATED
D
D
D
50kgx3
(110lbsx3)
RATED
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your distributor if you have any questions.
Note: The accessories
are not standard equipped.
The accessories will be
selected according to
user requirement.
Optional Accessories
2 1 3
5
8
4
7
6
9
Note: The displays are installed by the numerical order given.
Note: The angle of displays are adjusted by the numerical order given.
879
5
2
4
1
6
3
300x300 400x200/
400x400/600x400
WARNING
21
NOTE: Read the entire instruction manual before you start installation and assembly.
• Do not begin the installation until you have read and understood all the instructions
and warnings contained in this installation sheet. If you have any questions
regarding any of the instructions or warnings, please contact your local distributor.
• This mounting bracket was designed to be installed and utilised ONLY as
specified in this manual. Improper installation of this product may cause damage
or serious injury.
• Always use an assistant or mechanical lifting equipment to safely lift and position
the equipment.
• Tighten screws firmly, but do not over tighten. Over tightening can cause damage
to the items, This greatly reduces their holding power.
• This product is intended for indoor use only. Using this product outdoors could
lead to product failure and personal injury.
IMPORTANT: Ensure that you have receiv ed all parts according to the component checklist prior to ins tallation.
If any parts are mis sing or faulty, telephone your local distributor for a replacement.
AS01346FP
Package M (x3)
washer
M-F
(x4)
M8x20 (x4)
M-C
M5x14 (x4)
M-A
M6x14 (x4)
M-B
big spacer (x4)
M-H
M6x30 (x4)
M-D
M8x30 (x4)
M-E
small spacer (x8)
M-G
AS01K ( )The following accessories are optional
power socket (x1)
T-H
ST4.8x9.5 (x4)
P-G
adapter bracket (x6)
D
universal plate (x3)
C
connecting fitting (x3)
B
steel plate (x1)
A
rubber pad (x4)
F
column (x1)
E
connecting plate (x1)
G
top cover (x1)
H
iron expansion bolt (x6)
I
cable clamp (x12)
J
M8x16 (x4)
K
M8x16 (x6)
L
M8x40(x4)
M
5mm Allen key (x1)
P
6mm Allen key (x1)
Q
3mm Allen key (x1)
N
4mm Allen key (x1)
O
