Side 1/8

User Instructions

American DJ®

Customer Support:

American DJ provides a toll free customer support line, to provide set ®

up help and to answer any question should you encounter problems

during your set up or initial operation. You may also visit us on the web

at www.americandj.com for any comments or suggestions. For service

related issue please contact American DJ . Service Hours are Monday ®

through Friday 9:00 a.m. to 5:00 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

your nearest American DJ dealer.

PLEASE do not discard the shipping carton in the trash. Please

recycle when ever possible.

Safety Issues: This unit may blow a fuse if the maximum allotted

load of 15 amps is reached. If the fuse needs replacement, always

replace the fuse with same exact type that was remove, unless

otherwise instructed by an authorized American DJ service techni-®

cian. Use of a different type fuse from that which is recommended may

cause fire or electric shock and will void the manufactures warranty.

DJ Roller™ Unpacking

DJ Roller™ Introduction

Thank you for purchasing the DJ Roller™ by American DJ . Every DJ ®

Roller™ has been thoroughly tested and has been shipped in perfect

operating condition. Carefully check the shipping carton for damage

that may have occurred during shipping. If the carton appears to be

damaged, carefully inspect your unit for any damage and be sure all

equipment necessary to operate the system has arrived intact. In the

event damage has been found or parts are missing, please contact our

toll free customer support number for further instructions. Please do not

return the unit to your dealer without rst contacting customer support.

American DJ®

4295 Charter Street

Los Angeles, CA 90058

www.americandj.com

Revised 3/03

DJ Roller™ Quick Start

The DJ Roller™ features a bright 150 watt/500 hour lamp life halogen

bulb with a separate gobo and color wheel. The color wheel features

seven brilliant colors plus white and the gobo wheel features 9 gobos

plus a large and small spot. This units is ready to be installed or hung

and powered right out of the box. There is no assembly required. This

fixture incorporates the use of high quality stepper motors for a more

accurate mirror movement. Mirror movement allows for a full 90

degree tilt (vertical) and a full 90 degree pan (horizontal). An internal

built in microphone allows the fixtures to run in Stand Alone mode so

there is no need for an external controller. The DJ Roller™ may also

be set-up to run in a Master-Slave mode when used in multiples, up to

16 units. When used in the Master-Slave mode, the unit will chase to

several internal programs. The DJ Roller™ can also be controlled via

a standard DMX controller such as the American DJ Show Designer,™

or the American DJ DMX Operator,™ giving the user independent ®

control over the gobo and color wheel as well as the mirrors pan and

tilt movements.

• ZB-JCR/H5 15V/150W, 500Hr Lamp.

• DMX-512 Compatible.

• Stepper motors for smooth movements.

• 7 colors plus white.

• 10 Gobos plus spot.

• Master/Slave Operation

• Built-in microphone.

• Sound sensitivity knob.

• One year warranty.

• Sound Active.

• Optional MINI/C controller, for blackout control.

DJ Roller™ Features

Master/Slave Quick Start Stand Alone Mode

Connect up to four units together via XLR cables. The master unit

will run the slaves to the masters built in programs and internal

microphone. Plug in all units. When the DJ Roller™ is first turned on,

it will run through an internal self test where it resets all motors to their

zero position. After the self test the units will react to sound, and chase

to the several built in programs.

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required voltage

for your unit.

• Do not attempt to operate this unit if the power cord has been frayed

or broken. Please route your power cord away from foot trafc.

• Do not attempt to remove or break off the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the top cover under any conditions. There are no

user serviceable parts inside.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit if it becomes damaged in any way.

• Never operate this unit when itʼs cover is removed.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• This unit is intended for indoor use only, use of this product outdoors

voids all warranties.

• During long periods of non-use, disconnect the unitʼs main power.

• Always mount this unit in safe and stable matter.

• Power-Cord Protection -Power-supply cords should be routed

so that they are not likely to be walked on or pinched by items

placed upon or against them, paying particular attention to cords at

plugs, convenience receptacles, and the point where they exit from

the fixture.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer.

• Heat -The fixture should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (includ-

ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The fixture does not appear to operate normally or exhibits a

marked change in performance.

DJ Roller™ Safety Precautions
