American DJ

USER INSTRUCTIONS

FLASH 2C

Flash Tube Controller

FEATURES:

• THREE TRIGGER OPTIONS: AUDIO, MANUAL, AND AUTOMATIC

• PUSH BUTTON CONVENIENCE

• 19” RACK MOUNT, LED DISPLAY

• 4 FLASH PATTERNS: DOWN AND BACK, CRISSCROSS, BACK TO FRONT, AND FRONT TO

BACK

• SPEED AND RATE CONTROL

CONTROLS AND FUNCTIONS:

1. MASTER ON/OFF SWITCH - Press this button to switch the controller on and off.

2. LINE ON/OFF SWITCHES - These are on/off switches for the 4 flash tube lines.

3. BUTTON - This button will activate the down and back pattern.

4 BUTTON - . This button will activate the crisscross pattern.

5. BUTTON - This button will make the flash tubes run from the last tube to the first tube in

the

line.

6. BUTTON - This button will make the flash tube run from the first tube to the last tube in

the line.

7. SYNC BUTTON - Activates all 4 flash tube lines.

8. FLASH BUTTON - This button will activate the fastest speed and rate times.

9. AUTO BUTTON - This button will activate each flash tube line one-by-one. Starting with line 1,

then line 2

, etc.....

10. MANUAL BUTTON - This button allows you to manually trigger flash tube runs. First press this

button, and then press the trigge

r buttton to activate the runs.

11. SPEED CONTROL - With this knob you can control the speed of the flash tube patterns.

12. AUDIO BUTTON - This button activates sound active mode.

13. RATE CONTROL -

With this knob you can control the time of the flash in the flash tubes.

14. TRIGGER BUTTON - This will activate a run when the controller is in Manual mode.

1 2 876543 131211109 14

American DJ

USER INSTRUCTIONS

FLASH 2C

Flash Tube Controller

Specifications:

Model - Flash 2C

Maximum load: 15 amps or 1800 watts per relay pack (using

separate circuit for each).

Size: SC-8FC - 19” x 2” x 2”

SC-RP8 - 19” x 5” x 2”

System weight: 13lbs.

15 1716

CONNECTIONS AND FUNCTIONS:

15. FLASH TUBE CONTROLLER SOCKETS - Connect your flash tubes to these sockets.

16. BREAKER - This unit is equipped with a built-in 30 Amp safety breaker. This breaker is designed

to close the power circuit in the event of an internal short or power surge. This will reduce the risk of

electrical shock or ﬁre and protect the circuitry. To reset the breaker, push the breaker button in until

you hear it “pop” back in to place. If the breaker continues to pop, stop using the unit and contact

our customer support team, the unit may need to be returned for service.

17. POWER CORD - This cord is used to supply main power to the ﬁxture. Be sure the main power

matches the required power of your ﬁxture. The rated power requirements are clearly marked on the

rear panel of the unit.

OPERATING INSTRUCTIONS:

1. Attach your ﬂash tubes to the Flash Tube Sockets located on the back of the controller.

Note: After every ﬂash tube, connect a booster, and at the end of the ﬂash tube line, you

need to conncet a terminator.

2. Now plug the controller into matching power outlet.

3. Follow the functions on the front page to control the speed, rate, and patterns you desire.
