Side 1/4

User Instructions

American DJ

4295 Charter Street

Los Angeles Ca. 90058

www.americandj.com

Customer Support:

American DJ provides a toll free customer support line, to provide set ®

up help and to answer any question should you encounter problems

during your set up or initial operation. You may also visit us on the web

at www.americandj.com for any comments or suggestions. For service

related issue please contact American DJ . Service Hours are Monday ®

through Friday 9:00 a.m. to 5:00 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ.

PLEASE recycle the shipping carton when ever possible.

Safety Issues: This unit may blow a fuse if the maximum allotted

load of 5 amps is reached. If the fuse needs replacement, always

replace the fuse with same exact type that was remove, unless oth-

erwise instructed by an authorized American DJ service technician. ®

Use of a different type fuse from that which is recommended may

cause fire or electric shock and will void the manufactures warranty.

Image 250™ Unpacking

Image 250™ Introduction

Thank you for purchasing the Image 250™ by American DJ®. Every

Image 250™ has been thoroughly tested and has been shipped in

perfect operating condition. Carefully check the shipping carton for

damage that may have occurred during shipping. If the carton appears

to be damaged, carefully inspect your unit for any damage and be sure

all equipment necessary to operate the system has arrived intact. In

the event damage has been found or parts are missing, please contact

our toll free customer support number for further instructions. Please

do not return the unit to your dealer without rst contacting customer

support.

Rev. 10/07

Introduction: Thank you for purchasing the Image 250™ by American

DJ . For your convenience the Image 250™ has been lamped and is ®

ready to be used, there is no assembly necessary. There are 7 gobos,

1 instlalled, and 6 seperate. This unit includes a hanging bracket and

may be hung or set on a flat surface. For best results, use a fog or

haze machine to enhance the beam output. Please read the following

instructions before installing or operating your new Image 250.™

Operating Instructions: Plug the unit in to a matching power outlet

or into a power pack. Light output will be immediate when the unit is

powered on. You can reverse the wheel using the switch in back.You

can also adjust the speed by turning the knob located on the rear of

the unit.

Mounting: When used with included mounting bracket, this unit may

be mounted in any safe position or set on a flat stable surface.

Caution! Be sure not to obstruct cooling vents and keep this unit in a

well ventilated area. Never open the unit while in use. Avoid touching

the lamps, the lamp will get extremely hot under normal usage and

may cause serious injury.

Image 250™ Operation

Please carefully read and understand the instructions in this manual

thoroughly before attempting to operate this unit. These instructions

contain important safety information regarding the use and mainte-

nance of this unit. Please keep this manual with the unit, for future

reference.

Image 250™ General Instructions

Image 250™ Precautions

• Keep the outside of this device dry at all times. Do not spill water

or other liquids into or on to your unit. To prevent re or shock

hazard, do not expose this product to rain or moisture.

• Be sure to save the packing carton in the event you may have to

return the unit for service.

• This unit is designed for interior use only. Do not use this unit out

doors. Use of product outdoors will void the warranty.

• Be sure that the local power outlet match that of the required vol-

tage for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken.

• Always route your power cord out of the way of foot trafc.

• Do not attempt to remove or break off the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

shock and re in the rare case of an internal short.

• Disconnect the unit’s main power when left unused for long peri-

ods of time.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Never block the ventilation holes.

• Do not attempt to operate this unit, if it becomes damaged in any

way.

• Never operate this unit when it’s cover is removed.

• This unit is for adult use only. Keep out of the reach of children.

Due to fog residue, smoke, and dust cleaning the internal and exter-

nal optical lenses must be carried out periodically to optimize light

output.

1. Use normal glass cleaner and a soft cloth to wipe down the out-

side casing.

2. Use a brush to wipe down the fan grill.

3. Clean the external optics with glass cleaner and a soft cloth every

20 days.

4. Clean the internal optics with glass cleaner and a soft cloth every

30-60 days.

5. Always be sure to dry all parts completely before plugging your

unit back in.

Cleaning frequency depends on the environment in which the fixture

operates (I.E. smoke, fog residue, dust, dew).

Image 250™ Cleaning
