User Instructions

Pocket Scan™ Introduction

American DJ®

Rev 10/09

General instructions: To optimize the performance of this product,

please read these operating instructions carefully to familiarize yourself

with the basic operations of this unit. These instructions contain impor-

tant safety information regarding the use and maintenance of this unit.

Please keep this manual with the unit, for future reference.

Unpacking: Thank you for purchasing the Pocket Scan™ by Ameri-

can DJ . Every Pocket Scan™ has been thoroughly tested and has ®

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all accessories necessary to operate the unit has

arrived intact. In the case damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Do not return this unit to your dealer without rst contacting

customer support.

Introduction: The Pocket Scan

is part of American DJ’s continu-

ing pursuit for creating high quality affordable intelligent fixtures. The

Pocket Scan

is our most compact full featured scanner ever. The

Pocket Scan™ is a DMX scanner with a built-in 4.9mW diode laser.

Both the laser and the lamp can be operated at the same time for truly

amazing effects. This unit is light weight and compact which makes it a

great piece for mobile DJ’s and clubs. For best results use this unit with

a fog machine to enhance the output of the beams and laser.

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to 5:

00 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ .®

Pocket Scan™ Quick Start Pocket Scan™ Safety Precautions

Quick Start Stand Alone Mode

Connect all your units together via the XLR connector. You can

connect up to 16 units together in Master/Slave mode. The master

unit will run the slaves to the masters built in programs and internal

microphone. Plug in all units. When the Pocket Scan™ is first turned

on, it will run through an internal self test where it moves all motors to

their zero position. After the self test the units will react to sound, and

chase to the several built in programs.

• Scanner and Laser in one effect

• 4.9mW diode laser

• 15 colors plus white

• Split colors

• 13 gobos plus spot

• Separate color and gobo wheels

• High Speed Shutter with variable Speed

• 170 degree pan / 110 degree tilt

• Full Micro-stepping, with 4 stepper motors.

• Built in Microphone

• Auto switch to Stand-Alone (Master/Slave) operation

when DMX signal is disconnected

• Run up to 16 heads without controller

• DMX-512 protocol

• Full Focusing

• Fan cooled

• Uses 4 DMX Channels

• Digital DMX display

Safety Issue: This unit may blow a fuse if the maximum allotted load

of 2 amps is reached. If the fuse needs replacement, please see the

fuse replacement guidelines on page 13.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required voltage

for your unit.

• Do not attempt to operate this unit if the power cord has been frayed

or broken. Do not attempt to remove or break off the ground prong

from the electrical cord. This prong is used to reduce the risk of elec-

trical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product outdoors

voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

Pocket Scan™ Warranty Registration

The Pocket Scan™ carries a one yeare (365 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase.

All returned service items whether under warranty or not, must be

freight pre-paid and accompany a return authorization (R.A.) number.

If the unit is under warranty you must provide a copy of your proof

of purchase invoice. Please contact American DJ customer support ®

for a R.A. number.

Pocket Scan™ Features

DANGER

VISIBLE LASER RADIATION

-AVOID DIRECT EYE EXPOSURE

LASER DIODE

WAVELENGTH : 532 nm

Max Output : <4.9mW

Class IIIa Laser Product

CAUTION IMPORTANT! When installing this projector, make sure

that it is mounted in a manner that prevents the audience from

looking directly into the beam, and the beam from striking the

audience.
