Q-2422 MKII

Professional Preamp Mixer

4295 Charter Street

Los Angeles Ca. 90058

www.AmericanAudio.us

User Guide

and Reference Manual

Rev. 04/05

MAIN FEATURES....................................................................................................................................2

ELECTRICAL PRECAUTIONS................................................................................................................4

SAFETY PRECAUTIONS........................................................................................................................5

INTRODUCTION....................................................................................................................................6

SET-UP PRECAUTIONS.........................................................................................................................6

UNPACKING.........................................................................................................................................7

QUICK START.........................................................................................................................................7

FUNCTIONS AND CONTROLS

FRONT PANEL............................................................................................................................8

REAR PANEL............................................................................................................................12

CLEANING......................................................................................................................17

CROSSFADER REPLACEMENT.........

..................................................................................................17

TROUBLESHOOTING......................................................................................................................18

WARRANTY.........................................................................................................................................19

SPECIFICATIONS.....................................................................................................................20

CONTENTS Q-2422 MKII™

• Equipped with high quality Crossfader

(Replaceable)

• Optical Detecting Fader for Q-Start Control

• High Power Headphone Output

• Selectable Voltage 115v~230v

• 3 Channel Mixer

• 2 Phono, 4 Line, 3 Auxiliary Inputs

• 2 Microphone Input - (1) XLR/ 1/4" combo

plug, (1) 1/4" Input Jacks

• Volume Control for each Mic

• Master Balance Control

• 12v BNC Light Connector for Gooseneck

Light

• Fader "Q" Start

• On/Off Button Controls Fader "Q" Start

Function (for use with the American Audio

CD Players with Fader "Q" Start)

• Rotary Kills for Treble, Bass & Mids

on all three channels

• Individual Channel Gain Control

• Convenient "L" Shape Design

• Extremely clean signal to noise ratio

• Talkover switch- Reduces channel output

gain by 14dB +/- 2 dB

• Independent Zone Level Output

• Stereo LED Level Indicator

• Split Cue Monitoring

• Cue Mixing

• Balanced XLR Master Output

• 4 Signal Output Options - Master (RCA and

Balanced XLR), Zone (RCA)

and REC (RCA)

Specifications subject to change without notice.

FEATURES Q-2422 MKII™

Produkt Specifikationer

Mærke:	American Audio
Kategori:	Ikke kategoriseret
Model:	Q-2422 MKII
