©American Audio® - www.americanaudio.us - Q-SPAND PRO Instruction Manual Page 2
MAIN FEATURES....................................................................................................................................2
ELECTRICAL PRECAUTIONS................................................................................................................4
SAFETY PRECAUTIONS........................................................................................................................5
INTRODUCTION....................................................................................................................................6
SET-UP PRECAUTIONS.........................................................................................................................6
UNPACKING.........................................................................................................................................7
QUICK START........................................................................................................................................7
FUNCTIONS AND CONTROLS
FRONT PANEL.............................................................................................................................8
REAR PANEL.............................................................................................................................13
CLEANING......................................................................................................................18
CROSSFADER REPLACEMENT.........
..................................................................................................18
TROUBLESHOOTING......................................................................................................................19
WARRANTY.........................................................................................................................................20
SPECIFICATIONS.....................................................................................................................21
Q-SPAND PRO CONTENTS
• VCA Fader for Q-Start Control
• Adjustable Crossfader Curve - For Personaliza-
tion
• Single Voltage or Dual Voltage
• 3 Phono/4 Aux, 4 Line, & 3 Mic Inputs
• Q-Start Compatible (for use with American
Audio CD Players with Fader “Q” Start)
• Fader “Q” Start on channels 1 & 2
• Separate gain control for each channel
• High output to headphones
• Balanced XLR Output
• WOW Process
• Extremely clean signal to noise ratio
• Talk Over Button - Reduces channel output
gain by 14dB +/- 2 dB
• LED Level Indicators -
Indicates Master Level and Channel Levels
• Master Output Balance Control
• Split Cue Monitoring
• Cue Mixing
• Independent ZONE Output Level
• 12v Gooseneck Light Option
• -30dB Rotary Kills for Treble, Bass and
Mids on all channels
Q-SPAND PRO FEATURES
