American DJ ®

6122 S. Eastern Ave.

Los Angeles CA. 90040

www.americandj.com

Rev. 12/13

User Instructions

American DJ - www.americandj.com - Quad Gem DMX™ Instruction Manual Page 2®

Unpacking: Thank you for purchasing the Quad Gem DMX™ by

American DJ . Every Quad Gem DMX™ has been thoroughly tested ®

and has been shipped in perfect operating condition. Carefully check

the shipping carton for damage that may have occurred during ship-

ping. If the carton appears to be damaged, carefully inspect your x-

ture for any damage and be sure all equipment necessary to operate

the unit has arrived intact. In the event damage has been found or parts

are missing, please contact our toll free customer support number for

further instructions. Please do not return this unit to your dealer with-

out contacting customer support rst.

Introduction: The Quad Gem DMX™ is a DMX intelligent LED fixture.

When using DMX mode you can choose between a four channle mode

and a 10 channel mode. The fixture can operate in three different oper-

ating modes; stand alone active, or in a Master/Slave configu, sound- -

ration. The Quad Gem DMX™ comes with several buil in programs. t

When used as a stand alone unit or when used in multiples linked in a

master/slave configuration. For best results use fog or special effects

smoke to enhance the beams projections.

Customer Support: American DJ provides a toll free customer ®

support line, to provide help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to

5:00 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Warning! This may cause severe eye damage. Avoid looking directly

into the light source at all times!

Quad Gem DMX™ General Information

For Your Own Personal Safety, Please Read and Understand This

Manual Completely Before You Attempt To Install Or Operate

This Unit!

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken.

• Do not attempt to remove or break o the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to cords at plugs, convenience recep-

tacles, and the point where they exit from the appliance.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 14 for cleaning details.

• Heat -This fixture should be situated away from heat sources such

as radiators, heat registers, stoves, or other appliances (including

amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. Objects have fallen, or liquid has been spilled into the appliance.

B. The appliance has been exposed to rain or water.

C. The appliance does not appear to operate normally or exhibits a

marked change in performance.

Quad Gem DMX™ Safety Precautions

American DJ - www.americandj.com - Quad Gem DMX™ Instruction Manual Page 4American DJ - www.americandj.com - Quad Gem DMX™ Instruction Manual Page 3 ®®

• DMX-512 Protocol Compatible (Four or Seven DMX Channels)

• RGB + White

• 3 Operating Modes - Master/Slave; Stand Alone; Sound Active

• Internal Microphone

• Digital Display for Address and Function Setting

• UC3 Controller (Not Included)

• 12 Sound Active Shows

• Power Cord Daisy Chain

Quad Gem DMX™ Features

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ .®

American DJ® will not accept any liability for any resulting damages

caused by the non-observance of this manual or any unauthorized

modication to this unit.

Quad Gem DMX™ Handling Precautions

Quad Gem DMX™ Warranty Registration

The Quad Gem DMX™ carries a 3 year (1095 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase

and warranty. You may also register your product online at www.

americandj.com. All returned service items whether under warranty or

not, must be freight pre-paid and accompany a return authorization

(R.A.) number. If the unit is under warranty you must provide a copy

of your proof of purchase invoice. Please contact American DJ® cus-

tomer support for a R.A. number.

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Quad Gem DMX™ General Instructions
