Side 1/4

User Instructions

Saga II™ Introduction

Unpacking:

Thank you for purchasing the Saga II™ by American DJ . Every Saga ®

II™ has been thoroughly tested and has been shipped in perfect oper-

ating condition. Carefully check the shipping carton for damage that

may have occurred during shipping. If the carton appears to be dam-

aged, carefully inspect your unit for any damage and be sure all equip-

ment necessary to operate the system has arrived intact. In the event

damage has been found or parts are missing, please contact our toll

free customer support number for further instructions. Please do not

return the unit to your dealer without ﬁrst contacting customer sup-

port.

Customer Support:

American DJ provides a toll free customer support line, to provide set ®

up help and to answer any question should you encounter problems

during your set up or initial operation. You may also visit us on the web

at www.americandj.com for any comments or suggestions. For service

related issue please contact American DJ . Service Hours are Monday ®

through Friday 9:00 a.m. to 5:00 p.m. Paciﬁc Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or ﬁre, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war

ranty. In the unlikely event your unit may require service please contact

American DJ.

PLEASE recycle the shipping carton whenever possible.

11/04

American DJ®

4295 Charter Street

Los Angeles Ca. 90058

www.americandj.com

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Saga II™ General Instructions

Saga II™ Safety Precautions

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to remove or break off the ground prong from

the electrical cord. This prong is used to reduce the risk of electri-

cal shock and ﬁre in case of an internal short.

• Do not remove the unit cover under any conditions. There are no

user serviceable parts inside.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• To reduce the risk of electrical shock or ﬁre, do not expose this unit

rain or moisture.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• During long periods of non use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-Cord Protection - Power-supply cords should be routed so

that they are not likely to be walked on or pinched by items placed

upon or against them, paying particular attention to cords at plugs,

convenience receptacles, and the point where they exit from the

fixture.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer.

• The fixture should be serviced by qualified service personnel

when:

A. The power cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The fixture does not appear to operate normally or exhibits a

m arked change in performance.

Saga II™ Operation

Power Supply:

Before plugging your unit in, be sure the source voltage in your

area matches the required voltage for your American DJ

® Saga II.™

The American DJ

® Saga II

™

is available in a 120v and 220v version.

Because line voltage may vary from venue to venue, be sure to plug

your ﬁxture into a wall outlet with a matching power supply before

attempting to operate.

General Operation:

This fixture is designed to operate as a stand alone unit, there is no

need of a controller. The Saga II™ is ready to be plugged in, out of

the box. If there is no lamp output check the breaker and bulb. If the

breaker and bulb are good, please contact our toll free customer sup

port number for further instructions. Please do not return the unit to

your dealer without ﬁrst contacting customer support.

Mode Switches:

The Sage come with two mode switches on the rear of the unit.

Switch 1 controls the reflector dish, switch 2 controls the gobo wheel.

When the switches are in the up position (“I”) the wheels will rotate

a continuous rotation regardless of sound. When the switches are in

the middle position (“0”) the wheels will remain static (no rotation).

When the switches are in the down position (“II”) the wheels will react

to sound. Each wheel may be operated separately, so one wheel may

be controlled by sound while the other may be in a rotating in con

tinuous motion.

Saga II™ Warranty Registration

The Saga II™ carries a one year (365 days) limited warranty. Please

fill out the enclosed warranty card to validate your purchase. All

returned service items whether under warranty or not, must be freight

pre-paid and accompany a return authorization (R.A.)

number. The

R.A. number must be clearly written on the outside of the return

package. A brief description of the problem as well as the R.A. num

ber must also be written down on a piece of paper and included in

the shipping container. If the unit is under warranty, you must provide

a copy of your proof of purchase invoice. You may obtain a R.A. num-

ber by contacting customer support at (800) 322-6337.
