Side 1/6

American DJ ®

4295 Charter Street

Los Angeles, CA. 90058

www.americandj.com

07/03

User Instructions

Unpacking: Thank you for purchasing the Warp 250™ by American

DJ . Every Warp 250™ has been thoroughly tested and has been ®

shipped in perfect operating condition. Carefully check the shipping

carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all accessories necessary to operate the unit

have arrived intact. In the event damage has been found or parts are

missing, please contact our toll free customer support number for fur-

ther instructions. Please, do not return this unit to your dealer without

rst contacting customer support.

Introduction: The Warp 250™ uses 11 color/gobo combinations to

create a colorful hightech moonflower effect, that changes to the beat

of music. This unit is part of the Advanced Drive Series (ADS). Any unit

that has the ADS logo is designed to interconnect and work together.

When several ADS effects are linked together they can form an inex-

pensive system that creates an intelligent look. This unit is best used in

multiples of four or more. For best results mix and match several ADS

units together with a fog or haze machine to enhance the beam output.

An optional MINI/C controller may be purchased separately and will

control a blackout function.

Warning! The 1/4” jack on the unit is for the optional MINI/C. Do not

attempt to connect an audio signal to this jack, this will damage the

PC board and void your manufactures warranty!

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to 5:

00 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures

warranty. In the unlikely event your unit may require service please

contact American DJ customer support.®

Warp 250™ Introduction

ADVANCED

DRIVE SERIES

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit

• Do not attempt to operate this unit if the power cord has been fray-

ed or broken. Do not attempt to remove or break off the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short

• Disconnect from main power before making any type of connection

• Do not remove the cover under any conditions. There are no user

serviceable parts inside

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall

• Do not attempt to operate this unit, if it becomes damaged

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties

• During long periods of non-use, disconnect the unit’s main power

• Always mount this unit in safe and stable matter

• Power cords should be routed so they are not likely to be walked

on, pinched by items placed upon or against them.

• Cleaning -The xture should be cleaned only as recommended by

the manufacturer. See page 9 for cleaning details

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (in-

cluding ampliers) that produce heat.

• The xture should be serviced by qualied service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

• Advanced Drive Series Lighting Effect - Units Link Together with

other Advanced Drive Series Lights via XLR In and Out

• MINI/C Blackout Controller (Sold Separately)

• Fan Cooled

• 2 Sound Activated Modes: Slow Sound Active or Fast Sound Active

• Master/Slave Compatible

• Includes Built-In Mounting Bracket

• ZB-ELC 24v/250w Lamp

• Volume Sensitivity Knob

• 11 Gobos

• 10 Colors Plus White

Introduction..........................................................................2

Features................................................................................3

Safety Precautions...................................................................3

Operation..............................................................................5

Dipswitch Settings..............................................................6

Set-Up................................................................................7

Lamp Replacement...............................................................8

Cleaning.............................................................................9

Trouble Shooting.............................................................9

Warranty............................................................................10

Specifications...........................................................................11

Warp 250™ Warranty Registration

The Warp 250™ carries a one year (365 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase.

All returned service items whether under warranty or not, must be

freight pre-paid and accompany a return authorization (R.A.) num-

ber. The R.A. number must be clearly written on the outside of the

return package. A brief description of the problem as well as the R.A.

number must also be written down on a piece of paper and included

in the shipping container. If the unit is under warranty, you must pro-

vide a copy of your proof of purchase invoice. You may obtain a R.A.

number by contacting customer support at (800) 322-6337.

Warp 250™ Features

Warp 250™ Contents

Warp 250™ Safety Precautions

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Warp 250™ General Instructions
