Side 1/19

HONK828 Mounting Kit

Honda

1990-02 ACCORD

1999-00 CIVIC

2002-05 CIVIC SPECIAL EDITION

2006-12 CIVIC (see note below)

1997-06 CRV

2003-06 ELEMENT

2007-11 ELEMENT LX

1995-04 ODYSSEY

1989-01 PRELUDE

Izusu

1996-99 OASIS

VEHICLE APPLICATIONS

Acura

1997-99 CL

1990-01 INTEGRA

1986-96 LEGEND

1996-98 TL

1992-94 VIGOR *

*Note: This kit fits all vehicles with factory navigation radios or vehicles that do not come

with any factory radio. For vehicles that are equipped with the factory non-navigation

radios, part# HCB-8800/HCB8820 is required (sold seperately).

SINGLE DIN INSTALLATION

TOOLS REQUIRED:

A. Razor knife, or file (to cut or file the removed mounting tabs flush with the back

edge of the main bracket)

B. Pliers, or wire cutters (for mounting tab removal)

C. Phillips screwdriver (to attach side brackets to rear of pocket)

KIT PREPARATION:

1. Locate the HON-K828 main frame bracket.

2. Find the page that has the year and make of vehicle you are working on.

3. Locate the left and right side mounting brackets (if required) See example below.

4. Following the illustration on the page for your vehicle, remove all mounting tabs

from the main frame and file or trim flush with the rear edge of the main bracket.

5. Remove all mounting tabs from the left and right side brackets unless they are

lettered for your vehicle application.

6. Insert the left and right side brackets into the opening of the main frame as shown

in illustrations on page 4 and secure to rear of pocket with small screws supplied

with kit.

7. Insert DIN sleeve from your new radio into the radio opening of the installation kit.

8. Depress the tabs from inside the sleeves opening upward, outward, and downward to

secure sleeve to the installation kit.

Note: ISO trim ring (ITR-828) may not be useable on some DIN mount applications.

Example: radio’s with non-removable trim rings

KIT PREPARATION

IMB-828L

IMB-828R

Note: For best looking install, ISO mounting

is recommended whenever possible.

ATTENTION: See line #2 above for ALL vehicles

Vehicles below require brackets

IMB-828L&R for DIN and ISO

mount applications

Bracket set IRB-828L&R below are

also required for vehicles only

when ISO mounting radio.

1998-02 Honda Accord

2002-06 Honda CRV

2003-06 Honda Element

2007-11 Honda Element LX

1999-04 Honda Odyssey
