Description
AW VideoCompositor gives system integrators and developers all the tools they need to easily incorporate
LiveCore™ image processors video compositing into a single point of control Crestron® touch-screen
application.
Version 4.01 adds new features, such as the support of multiple screens sharing the same source list in one
page, and the capability to assign sources to video layers either with drag and drop gesture, or just by
selecting a source and clicking the target layer.
These new features require new Smart Graphics™ module named AW Multi Display Composer. This new
module replaces old AW Video Compositor module (no backward compatibility).
Package content
The package contains the following components:
The Smart Graphics™ modules. They can be installed easily via the Windows setup application
provided. There are 4 different Smart Graphics™ modules automatically installed:
o AW Multi Display Composer
o AW Video Perspective Renderer (optional)
o AW Frames/Logos Configurator (optional)
o AW Text Entry (optional)
The Crestron driver for the LiveCore™ image processors
Two SIMPL+® example programs (one basic and one advanced)
Two XPanel projects (one basic and one advanced) running with the SIMPL+® sample programs
provided
Help files in English
Key features
Visualize all your screens with layers size and position (PRG or PRW)
Use the touchscreen to resize or adjust layer position
Visualize live sources with their dynamic thumbnail
2 modes for source selection: drag & drop or select & click
Recall Presets or Master Presets and start seamless transitions
Also compatible with Perspective Layer screens
Change the native background instantly
Configure the Monitoring mosaic with a simple flick of the finger
Configure Confidence screen(s) layout and load Presets
All Smart Graphics™ modules can be customized to match the look and feel of your application
Video Compositing Smart Graphics™ module can be configured to match your exact screens
configuration (pixel area, layers, …)
Compatible with 3-Series Crestron® control systems with Ethernet connection
Compatible with any LiveCore™ seamless switcher
