QUICK START GUIDE

Rackmount Control Unit Ref. RCU300–

Go to our website to register your

product(s) and be notied about

new rmware updates:

hp://bit.ly/AW-Register

LEDs (see Section below)

Startup/Shutdown

Double Power Supplies

Connecon panel

USB Ports

Thank you for choosing Analog Way and the . By following these Rackmount Control Unit

simple steps, you will be able to install and use your device. RCU

RCU is a rack mountable master control unit that combine and control mulple Analog Way

LiveCore

image processors to create a large-scale system soluon for video wall applicaons

that require a large amount of inputs, outputs and layers.

WHAT’S IN THE BOX

•

•• 1x Rackmount Remote Control Unit

•

•• 2x Power Supply cords

•

•• 1x RJ45 Ethernet cable

•

•• 1x Rack rail kit

•

•• 1x Screw kit

•

•• 1x Quick Start Guide

•

•• 1x Safety instrucon

Quick Start Guide is available on www.analogway.com

PANEL DESCRIPTION

FRONT PANEL

REAR PANEL

SET UP THE RCU

Step 1 Take the inner member (smaller slide channel) apart by

sharply pulling the front acvang release latch forward.

Step 2 Each slide is pre-aached with front and rear adjustable

brackets. Loosen the nuts on the both brackets, and

decide the proper setback distance to the opening, then

ghten the nuts on the front brackets.

Step 3 Extend the rear brackets to where it reaches the rear rack.

Do not fully ghten rear bracket screws unl nal adjustment is made.

Repeat step 2 & step 3 above for other side of outer slide member.

Step 4 For chassis width of 430mm, aach the L-shaped bracket to

the front mounng ange using screw & nylon ring from

screw kit (bar nut kit is oponal for your selecon).

For chassis width over 430mm, aach the L-shaped bracket

to the back of the mounng ange using screw & nylon ring

from screw kit.

Step 5 For chassis width of 430mm, aach the L-shaped bracket to

the rear mounng ange using & nylon ring from screw kit,

then ghten rear bracket mounng.

For chassis width over 430mm, aach the L-shaped bracket

to the back of the mounng ange screw & nylon ring from

screw kit.

Repeat step 4 & step 5 for the other side of the slide.

Step 6 Aach the inner slide member to your RCU using screw from

screw kit.

Produkt Specifikationer

Mærke:	Analog Way
Kategori:	Fjernbetjening
Model:	RCU300
Tænd-/slukkontakt:	Ja
Bredde:	510 mm
Dybde:	426 mm
Højde:	88 mm
Vægt:	11700 g
Produktfarve:	Sort
Produkttype:	Styreenhed
Pakkevægt:	17500 g
Relativ luftfugtighed ved drift (H-H):	10 - 80 %
Antal HDMI-porte:	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	6
Driftstemperatur (T-T):	0 - 40 °C
Indgangsspænding for vekselstrømsadapter:	100 - 240 V
Hurtig start guide:	Ja
Certificering:	IEC/UL/EN 60950-1, CSA22.2#60950-1, ETL Listed (US\n&Canada)
Strømforbrug (maks.):	115 W
Strømforsyningens indgangsfrekvens:	50 - 60 Hz
Mikrofonindgang:	Ja
Strømledning inkluderet:	Ja
Indgangsstrøm:	6 A
Antal DisplayPorts:	1
Udgang til hovedtelefoner:	Ja
Ethernet-grænsefladetype:	Gigabit Ethernet
Stativ-montering:	Ja
Varmeafgivelse:	392 BUT/t
RS-232-porte:	2
Antal RJ-45-porte:	2
Skruer inkluderet:	Ja
Antal DVI-porte:	1
Rackkapacitet:	2U
Rack skinner:	Ja
Antal USB 2.0 type-A-porte:	4
Hot-swap PSU:	Ja
Støjniveau (front):	54 dB
Støjniveau (bagerst):	56 dB
Dimensioner (B x D x H) (med håndtag):	545 x 483 x 88 mm
Antal køleblæsere:	2
