Quick Setup Guide (Version 8)

Two Year Warranty

Andover Audio warrants Spinbase against manufacturing defects and workmanship to the initial purchaser

for a period of one (1) year from the date of delivery to customer. Andover Audio will repair or replace the

unit as necessary to restore proper operation. This warranty covers both parts and labor for the warranty

period. The warranty excludes physical damage caused by accident or abuse outside of our control. If you

think you need warranty service, please contact us to obtain an RMA (Return Merchandise Authorization) by

emailing support@andoveraudio.com or calling 978.775.3670. Please visit our website’s support section

for more information about returns and exchanges.

Spinbase Setup

1. Remove Spinbase from its box. Keep the

packaging for returns or exchanges.

2. Place Spinbase on a level surface. This is

important for your turntable performance.

3. Before turning it on, plug Spinbase into a

power outlet using its power adapter.

Connect a Turntable or Record Player

1. Place your turntable on top of Spinbase.

2. Using a turntable with a Magnetic cartridge

(most common): Connect your turntable to

“Magnetic Phono”. Ensure switch is set to

“Line-In”.

3. Using a turntable with a Ceramic cartridge,

or a record player with a line output:

Connect it to the Line-In on Spinbase. Set

switch to “Ceramic”.

4. Use the ground connector if your turntable

supports it.

5. Leave shorting plugs in the “Magnetic

Phono” input when it’s not being used.

Connect a Bluetooth Device

1. Connect to “Spinbase” in your Bluetooth settings.

2. Disconnect Bluetooth for another device to pair.

Notice: Some users may experience an unpleasant noise when powering Spinbase on/

off while their headphones plugged in. Please be aware.

Visit our website’s support section for the latest product manuals.

Thank you for purchasing Spinbase.

If you’re new to vinyl, or returning to it after a few years, there are some important things to know:

The turntable Phono cartridge is the device on the end of the tonearm that converts record grooves to an

electrical signal. The most commonly equipped cartridges are and . Spinbase is compatible Magnetic Ceramic

with both, but the connections are different. (Note: Some high-end cartridges, called Moving-Coil, are not

compatible with Spinbase.)

MAGNETIC CARTRIDGES - provide higher delity than their Ceramic siblings. They also track your records with

less weight and are better at preventing record wear. They provide very little electrical output and require a

circuit known as an RIAA preamplier to boost and equalize the signal. Spinbase has this preamplier built-in.

If your turntable has a Magnetic cartridge, connect it to the “Magnetic Phono” input on Spinbase. Ensure the

back switch is set to Line-In.

Some turntables also have their own preampliers built-in and do not require the use of the preamplier

in Spinbase. If your turntable has a switch on it marked “Line” and “Phono”, your turntable has a built-in

preamplier. You have two choices:

1. Switch your turntable to “Line” and plug it into the Line-In input on Spinbase; or,

2. Switch your turntable to “Phono” and plug it into the “Magnetic Phono” input, utilizing the preamplier in

Spinbase.

In most cases, plugging your turntable into the Spinbase Phono input and ensuring back switch is set to Line-

In will give the best sound. Try them both and use what sounds best to you.

CERAMIC CARTRIDGES - are generally found in lower priced turntables and record players. They do not

perform as well as a good magnetic cartridge, but can still give satisfying performance with Spinbase thanks

to its exclusive Ceramic Equalization feature. Ceramic cartridges have high output voltage, and turntables or

record players equipped with one should be plugged into the Line-In input on Spinbase. The sound quality will

be improved when setting the back switch to “ON”. If you are NOT using a Ceramic cartridge, leave the back

switch to the Line-In position.

SHORTING PLUGS The shorting plugs supplied with Spinbase should remain plugged into the “Magnetic -

Phono” input whenever it is unused, such as when you are using the Spinbase Line-Input or a Bluetooth device.

Failure to do this will result in excess electronic background noise.

STAYING GROUNDED - Because Magnetic Phono cartridges have such a low output, the Phono input is much

more sensitive to any noise or ground hum than other inputs. Because of this, many turntables are equipped

with a grounding wire or have a screw to attach one. If your turntable requires grounding, attach the grounding

wire from the ground thumbscrew on Spinbase to the ground screw on your turntable. Some turntables are not

equipped with ground wires, and instead have their ground supplied through the RCA plugs.

CONTACT SUPPORT - There are so many different turntables, record players and other sources available to use

with Spinbase that it’s impossible to cover all the possibilities here. If you have any operation, connection, or

performance questions or concerns don’t hesitate to reach out to us. We’re ready to help!

support@andoveraudio.com | +1 978.775.3670

FCC STATEMENT: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.
