1. Introduction
2. Start to start working-up: what to do
3. Safety instructions
1. INTRODUCTION
The VAR3030 battery is a Lithium Polymer (Li-Po) backpack type battery with a
capacity of 30Ah, voltage 30V, with an internal electronic card for managing the
VAR600 machine.
The management card parameterizes the number of revolutions of the machine,
its absorption, guaranteeing maximum operating efficiency.
On the battery backpack there is an analog display that shows the battery charge
level; next to it is the input connector for the supplied battery charger.
2. START-UP: WHAT TO DO TO START WORKING
The VAR 3030 has an on/off switch that enables and disables battery power.
Warning
Warning
Warning
WarningWarning
When switching on the battery, always check that the switch on the VAR600
combine is in the OFF position.
a) Connect the backpack battery cable to the machine cable using the
appropriate female male connectors-
b) Press the power switch located on the VAR3030 battery pack
c) Press the switch of the machine
3. SAFETY INSTRUCTIONS
The operator must use the VAR3030 adopting all the safety measures required by
current regulations.
In particular, you must:
• ALWAYS and ONLY use the VAR3030 with the VAR600 machine.
• ALWAYS and ONLY use the supplied battery charger.
• DO NOT use VAR3030 in case of rain, electrical storms and in any case
always work in dry conditions.
• Always check the state of charge of the battery before each use.
• After use, disconnect the electrical connection and store the VAR3030 in a
cool, dry place.
• Recharge even during idle period, at least once every two months
