DA SDI- -HDTV -UHD
User Manual
HDMI 2.0 to 12G SDI
Converter w/o
Scaler
OVERVIEW
DA SDI- -HDTV - UHD is a HDMI UHD to 12G SDI converter. It
supports HDMI 2.0, 1. (including 4K30Hz and 4K60 4:2:0) 4
input and converts to SDI up to 1 tput with 2G SDI ou
optional SDI fiber output
PACKAGE CONTENTS
• DA- - - HDTV SDI UHD
• Locking Power Supply (12V/3.34A)
• Magnetic Mounting Plate
FEATURES
• Supports HDMI 1.4 and HDMI 2.0 input
• HDCP Compliant
• HDMI loop out
• Supports up to 12G SDI output
• 1 x SDI output
• 1 x SFP output for optional SDI SFP
SPECIFICATIONS
Functio
Functio
Functio
FunctioFunction
n
n
nn
DA
DA
DA
DADA-
-
-
-- -
-
-
--
HDTV
HDTV
HDTV
HDTVHDTV SDI
SDI
SDI
SDISDI-
-
-
--
U
U
U
UUHD
HD
HD
HDHD
D ESCRIPTION
HDMI 2.0 2G C (UHD) to 1 onverter with
Looping HDMI input
V I IDEO NPUT
1 x HDMI 2.0
INPUT RESOLUTIONS
HDMI 1.4 2.0 up to 3840x216/ 0P
VIDEO OUTPUT
1 x HDMI Loopout, , 1 x SF1 x SDI P
OUTPUT RESOLUTIONS
Up to 12G SDI
AUDIO OUTPUT
8 Channels of SDI Embedded Audio,
AES/AA stereo pairs
ROTARY SWITH
Audio pair selection
RS- 232
FW Upgrade Port
POWER
12V DC 3.34A
POWER LOOP OUT
1 2V DC 3.34A
Cable Distance
10 m 4on Certified K C ables
Housing
Metal
FRONT VI
FRONT VI
FRONT VI
FRONT VIFRONT VIEW
EW
EW
EWEW
1. LED for I/O SFP status
2. SFP cage for optional SDI Fiber Tx
3. LED for SDI status
4. SDI output
5. HDMI Loopout
6. HDMI Input
REA
REA
REA
REAREAR VIEW
R VIEW
R VIEW
R VIEWR VIEW
1. 232 RS-
2. AA monitoring output
3. AES monitoring output
4. Rotary switch for audio pair selection
5. Selection switch for BNC or SFP output
6. LED for HDMI status
7. 12V DC Loop out to power external device
8. 12V DC input
TOP VIEW
TOP VIEW
TOP VIEW
TOP VIEWTOP VIEW
INSTALLATION
• Connect the power supply
• Connect a certified 4K HDMI signal to the HDMI input
• Connect the SDI output to the receiving device via a
12G rated coax cable
• Use the rotary switch to select the stereo pair for AA
or AES monitoring output
• Insert the optional SDI SFP, if fiber output is needed
A S CCESSORIE
• 12V 3.34A power supply
HDMI PINOUTS
HDMI PINOUTS
HDMI PINOUTS
HDMI PINOUTSHDMI PINOUTS
Pin#
Signal
Pin#
Signal
1
TMDS Data 2+
11
TMDS Clock Shield
2
TMDS Data 2 Shield
12
TMDS Clock
3
TMDS Data 2-
13
CEC
4
TMDS Data 1+
14
Reserved
(N. C on device)
5
TMDS Data 1 Shield
15
SCL
6
TMDS Data 1-
16
SDA
7
TMDS Data 0+
17
DDC/CEC Ground
8
TMDS Data 0 Shield
18
+5 Power
9
TMDS Data 0-
19
Hot Plug Detect
10
TMDS Clock +
© 2019 APANTAC LLC, All rights reserved
APANTAC reserves the right to change the product specification without
prior notice.
1 S 0200 W ALLEN BLVD, STE C
BEAVERTON, OR 97005, USA
PHONE +1 503 968 3000, FAX +1 503 389 7921
The content of this document are provided in connection with Apantac s
LLC (“Apantac”) products. Apantac makes no representation or
warranties with respect to the accuracy or completeness of the contents
of this publication and reserves the right to make changes to
specifications and product descriptions at any time without notice
