DA-SDI-DE
USER MANUAL
SDI Audio De-Embedder
DA-SDI-HDTV FRONT VIEW
1. Rotary Switch for selecting audio monitoring pair,
0 = pair 1, 1 = pair 2, 2 = pair 3, 3 = pair 4, 4 =
pair 5, 5 = pair 6, 6 = pair 7, 7 = pair 8
2. Analog Audio monitoring stereo phone jack
3. AES or AA breakout (Needs DB25 Breakout Ca-
ble.)
1. Status Indicator - Turns Green when powered
on, turns amber when SDI signal is locked on
2. Real time LED audio meters. 2 = Group 1, 3
= Group 2, 4 = Group 3, 5 = Group 4
DA-SDI-HDTV REAR VIEW
DA-SDI-HDTV TOP VIEW
1. Power Supply Fastener
2. 5V 3.2A Power Input
3. AES Audio output
4. SDI Loop Out 2 (Terminator should be applied
when not in use)
5. SDI Loop Out 1
6. SDI Input
© 2012 APANTAC LLC, All rights reserved
7556 SW BRIDGEPORT ROAD
PORTLAND, OR 97224, USA
PHONE +1 503 968 3000
FAX +1 503 389 7921
The content of this document is provided in connection with
Apantac LLC (“Apantac”) products. Apantac makes no represen-
tation or warranties with respect to the accuracy or complete-
ness of the contents of this publication and reserves the right to
make changes to specifications and product descriptions at any
time without notice.
