Side 1/2

Connecting the ACP or ACPL panel

1. Switch of the power of your APart active speaker

2. Connect the ACP or ACPL unit to your active

speaker (through CAT5 cable max 100 meters,

maximum wire length depends on multiple factors,

such as cable quality and external influence from

high power lines etc.)

3. Only one ACP or ACPL can be connected to each

each APart active speaker pair.

ACP - ACPL - ACPR

User manual

The main features.

• In wall mountable remote control for APart active

speakers to control the speakers in your meeting-

room, class room etc.

• Brushed aluminium front.

• The ACP, ACPL and ACPR do not require an

additional power supply.

• The ACP allows remote power on/off, Volume control

and direct muting.

• The ACPL has the same features as the ACP plus a

selectable microphone or stereo line input.

• The ACPR has the same features as ACP plus offers 2

line inputs. One at the front on minijack, and one on

euroblock at the back. When a jack is plugged in the

front input, the rear input is automatically disabled.

• The stereo line inputs on the ACPL and ACPR

panel have an increased input sensitivity and are

compatible with the headphone outputs of most

portable music players.

• The panels have a power indication LED allowing

the user to visually see the power status of their APart

active speakers.

• Easy mounting in most popular in-wall mounting box

such as the APart E-MODIN.

• Connection between the panels and the active speaker

is done by a standard Cat5 cable.

Using the ACP(L)(R) panel

After installing and connecting the ACP(L)(R) panel to

your APart active speakers, you can switch on the power

switch of your APart active speakers. (use the power

switch at the backside of the speaker set)

With the “Power” button on your ACP(L)(R) you can

now put your active speakers in either “on” mode or

“standby” mode.

With the “level” buttons you can control the volume

of your APart Active speakers through the ACP. Note

that the maximum selectable volume level needs to be

selected at the backside of your APart active speaker.

When double clicking the “level down” button, you

will mute the system. Pushing the level up button once

disables the mute function.

Before you are able to use the inputs from the ACPL or

ACPR, you need to select this as a source at your APart

active speakers. For example for SDQ5PIR, you can

select the input through the IR remote control.

You can connect a Dynamic microphone to the ACPL

by using the “microphone” jack.6.3 mm (balanced

mono input).

You can connect an MP3 player to the ACPL or ACPR

by using the “Stereo Line” jack. 3.2 mm stereo mini-

jack (unbalanced stereo input).

With the button “input switch” you can select the ACPL

input you want to hear: mic or stereo line.

The ACPR panel has a line input at the rear on eurob-

lock connectors and one 3.2 mm stereo jack input on

the front panel. This rear line input is in use when no

jack is inserted in the front panel jack connector. Insert-

ing a jack automatically disables the rear line input.

* Note the selection of the audio input is only selectable for the

inputs from the panel itself. It cannot control inputs that are con-

nected directly to your Apart active speaker.

Using the local inputs of the ACPL / ACPR
