APart SDQ5-BL Manual

APart Højttaler SDQ5-BL

Læs gratis den danske manual til APart SDQ5-BL (1 sider) i kategorien Højttaler. Denne vejledning er vurderet som hjælpsom af 26 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 13.5 anmeldelser. Har du et spørgsmål om APart SDQ5-BL, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

SURFACE MOUNT LOUDSPEAKER

SDQ5

WWW.APART-AUDIO.COM INFO@APART-AUDIO.COM

• type : 2-way hiFi Pro, sealed box

• woofer : 5,25” CP type

weeter : 1” mylar ferro cooled

protection : system auto-reset 1-guard

mpedance : 8Ω

RMS power low-imp.

AES rated : 70 Watts

music - program : 80 Watts

dynamic peak : (lo-cut) 250 Watts

SPL 1 watt / 1 m : 91dB

SPL max peak : 115dB

Freq range : 70 - 20000 Hz

dispersion : 120° H x 100° V

P rating : 54

enclosure material : enforced PolyPlastic

bracket included : U-type

dimensions (h x w x d) : 244 x 179 x 154

weight : 2,07 Kg

Technical Specifications

The APart SDQ5 2-way design cabinet loudspeaker probably is one of the most

cost-effective loudspeakers for the contractor market.

The SDQ5 is equipped with an auto-reset protection system.

It makes the SDQ5 loudspeaker very suitable for the distribution of background music.

The loudspeaker comes standard with a U-type bracket.

The SDQ5 loudspeakers can be used outdoor. However, be aware of the fact that the

loudspeaker terminals are not protected and that the grill is made of plasticized

painted metal.

This means direct exposure to rain or water is not recommended.

In case this is really needed, we recommend to use the APart MASK loudspeaker series.

Produkt Specifikationer

Mærke:	APart
Kategori:	Højttaler
Model:	SDQ5-BL
Type:	I væggen/på væggen/i loftet højttalere
Vægt:	2070 g
Produktfarve:	Sort
Udgangseffekt (RMS):	70 W
Dimensioner (BxDxH):	179 x 154 x 244 mm
Frekvensområde:	70 - 20000 Hz
Impedens:	8 ohm (Ω)
Lyd-output kanaler:	2.0 kanaler
Diskanthøjttaler:	Ja
Peak Music-Udgangseffekt (PMPO):	100, 250 W
Diskant diameter:	25.4 mm
Woofer diameter:	133.4 mm
