Side 1/6
Electric Pump
User Manual
Model: Airbird C4
Thank you for purchasing this portable air pump. Please
read this user manual carefully before using the product and
keep it properly for reference in the future.
• Do not leave during inflation.
• Please do not put the electric pump near inflammable and
explosive items.
• Try to avoid moist,sediment invasion and fall.
• Do not store the product in a place that is too cold, too hot or
too humid.
• Built-in lithium battery, Do not throw the product into the fire or
throw it away casually.
• Keep the product away from the children.
Power on
Long press the power button for 3
seconds to power on.
Power o
Long press the power button for 3
seconds to power o.
Type-C charging input 5V/2A. Connect
the charging cable to the pump and
the power adapter (you need to buy
your own) to charge the pump.
Power indicator bar in charging state:
Indicator bar flashing: charging When
the indicator bar is long bright: it is full
Tips: Do not use the pump during
charging.
Use a ball needle when inflating
basketball, football and other balls.
Inflation: press the ball needle and
the Schrader Valve interface tightly
and insert into the ball to inflate.
When the air pump is on, after
the air hose is connected to the
inflation pressure detection object,
the figure in the upper part of the
air pump display is the measured
pressure value.
Press the working mode key to select
5 inflatable scene modes, as:
Actual
Pressure
Preset
Pressure
Mountain bikes, electric bikes,
motorcycles, cars will be equipped with
Schrader Valve.
Inflation: Connect the Schrader Valve
with the Schrader Valve interface on
the high pressure air hose to inflate.
Road bikes and some mountain bikes
need to use Presta Valve adapters
when inflating.
1. Connect the Presta Valve adapter
with the Schrader Valve interface on
the high pressure air pipe.
2. Unscrew the Presta Valve cap of
the tire.
3. The Presta Valve can be connected
with the converter to inflate.
Use Schrader Valve first to attach
the Dunlop Valve.
Schrader Valve (+Dunlop Valve
Presta Valve Adapter
Ball Needle
Dierent indicator color on the power
indicator bar show dierent power
Green: 70%-100%
Yellow: 30-70%
Red: 5%-30%
Red Flash: below 5% In low power
state, need to charge before use.
Under the power on state, press the
Start/Stop button to start inflation
and automatically stop inflation when
the preset pressure value is reached.
1. Power on and o
4. Charging Type
5. Connect the air hose to the air nozzle
2. Battery Indicator
3. Start/Stop Button
Portable Electric Pump Precautions User Guide
6. Check the air pressure
7.Application scenario switch
Packing list
Specification
1 x Air pump 1 x Ball needle
1 x Schrader Valve air hose 1 x Dunlop Valve
1 x Type-C Cable 1 x Presta Valve
1 x Storage Bag 1 x Manual
Scene
Mode
Reference Default
Values
Adjustable
Range
Car 35PSI 2-65PSI
Motorcycle 40PSI 2-55PSI
Bicycle 38PSI 2-150PSI
Ball 8PSI 2-15.0PSI
Custom 36PSI 2-150PSI
Product Dimension 68×48×154mm
Product Net Weight 451g
Max Air Pressure 10,3 BAR - 150 PSI
Working Temperature -10~45°C
Battery Capacity 2x2000 mAh / 7.4V / 14.8Wh5V
Input Parameter 2A
USB Output 5V-2A
[a] Actual Pressure
[b] Unit Display
[c] Preset Pressure
[d] Battery Indicator
[e] Mode Display
[f] Preset +
[g] Preset-
[h] Mode/Tire Forward
[i] Mode/Tire Backward
[j] Power Switch/ Start-Stop
[k] LED Light Switch
[l] Type-c Input /
output
[o] USB
Output
[p] Air Hose
Interface
[m] LED Light
[n] Air Hose
Storage
Power on
Nozzle
type
Nozzle
type
Nozzle
type
Power o
Inflation
connector
Inflation
connector
Inflation
connector
8
P
si
