AIK8-810B4 - NVR Kit - NVR - Specifications
Model
AIK8-810
Video/Audio Input
IP Video Input
PoE IP camera x 8
Audio Input
Cameras with built-in mic
Video Output
VGA, HDMI
Display Resolution
HDMI: 1-ch, resolution: 4K(3840*2160), 1920x1080, 1280x1024, 1280x720
VGA: 1-ch, resolution: 1920x1080, 1280x1024, 1280x720
Audio output
1-channel, RCA
Decoding
Video Format
H.264/H.264+
Synchronous Playback
Up to 4 channels
HDD
SATA
1 x SATA interface (1 x 2TB HDD included)
External HDD
1 eSATA interface for HDD
Capacity
Up to 10TB
External Interface
USB Interface
2 x USB 2.0
Network Interface
1, RJ-45 10/100 Mbps self-adaptive Ethernet interface for LAN/WAN
8, RJ-45 10/100 Mbps self-adaptive PoE Ethernet interface for IP camera
PoE
Max. Power Per Port
15.4W
Supported Standard
IEEE 802.3af/at
Network
Network Protocol
IPv4, DHCP, NTP, ONVIF,RTSP
WEB
Supports edge, Chrome (login through APP account)
OS Supported
PC: Windows, Mac OS; smartphone: iOS, Android
General
Power Supply
DC 48V
Power Consumption
Max. 45W (without HDD)
Working Environment
Temperature: -10°C~55°C (14°F~131°F); humidity: 10%~90%
Dimensions
280 x 230 x 47mm (W × D × H)
Weight
1000g
Warranty
Limited Warranty
2-year limited warranty. For support, visit https://support.reolink.com/hc/en -us/.
Accessories
Accessories
- Power cable: 1 × NVR power cable , 1 × HDD data cable, 1 x HDD power cable
- Ethernet cable: RJ45, Cat5e UTP, 1 m (Connects NVR and Switch)
- Mouse: 1 pcs
- Manual: 1 pcs
- Screw pack: 2 packs (for hard drives)
AIK8-810B4-NVR-Kit-IP-Camera-Specifications
Model
B4
Note:
The cameras of the kit cannot work without the NVR.
Camera
Image Sensor
1/2.7'' 8Megapixel CMOS
Effective Pixels
3840(H) × 2144(V)
Lens
f=4.0 mm Fixed, F=1.6
Angle of View
95°/50°/110°
Day/Night Mode
Auto(ICR)/Color/B&W
Min. Illumination
Color 0.1Lux@F1.6;
Black/White 0Lux@F1.6(Infrared)
IR Distance
Night visibility up to 10m
Shutter
1/25~1/1000s
WDR
DWDR
Video
Compression
H.264/H.264+
Resolution
3840 x 2144
Bitrate
32Kbps~4Mbps
Frame Rate
20fps
Sub Stream
640 x 360
Audio
Interface
Built-in Microphone
Network
Streaming Connections (Max)
2-ch main stream, 2-ch sub stream
Communication Protocol
HTTP, DHCP, DNS, TCP/IP, RTSP
Mobile Phone OS
App (iOS 9 or later, Android 5 or later), PC client
WEB Browser
Supports edge Chrome (login through APP account)，
Interface
TF Card
Yes, Max.256GB
Communication
1 RJ45 10M/100M adaptive network port, supporting PoE
Power Interface
DC female head 5.5 * 2.1
General
Power Supply
DC12V & PoE (IEEE 802.3af 48V Active)
Power Consumption
PoE: AC 48V, 0.5A, consumption: Max.5W
Working Environment
Temperature: -10°C~55 °C (14°F~ 131°F); humidity: 10%~90%
Ingress Protection
IP66
Dimension
160 x 75 x 64mm
Weight
330g
