Asrock H77M Manual

Asrock Bundkort H77M

Læs gratis den danske manual til Asrock H77M (68 sider) i kategorien Bundkort. Denne vejledning er vurderet som hjælpsom af 57 personer og har en gennemsnitlig bedømmelse på 4.7 stjerner ud af 29 anmeldelser. Har du et spørgsmål om Asrock H77M, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/68

H77M

User Manual

Version 1.1

Published July 2012

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Produkt Specifikationer

Mærke:	Asrock
Kategori:	Bundkort
Model:	H77M
Bredde:	244 mm
Dybde:	216 mm
Antal HDMI-porte:	1
HDCP:	Ja
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	6
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Maksimal opløsning:	2048 x 1536 pixel
Lyd-output kanaler:	7.1 kanaler
Certificering:	FCC, CE, WHQL, ErP/EuP
Strømkilde type:	ATX
Maksimal intern hukommelse:	16 GB
On-board grafikkort:	Ja
Mikrofonindgang:	Ja
S/PDIF-udgang:	Ja
Processorproducent:	Intel
Drivere inkluderet:	Ja
HDMI-version:	1.4a
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Komponent til:	PC
Antal PS/2-porte:	1
Processor sokkel:	LGA 1155 (Socket H2)
PCI Express slots version:	2.0,3.0
PCI Express x16 slots:	2
Understøttelse af parallel behandlingsteknologi:	2-Way CrossFireX,4-Way CrossFireX
DirectX-version:	11
Kompatibel processor serie:	Intel Core i3,Intel Core i5,Intel Core i7
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel H77
Understøttede hukommelsestyper:	DDR3-SDRAM
Antal hukommelsesstik:	2
Hukommelses slots type:	DIMM
Ikke-fejlkorrigerende kode:	Ja
Understøttede hukommelsesclock-hastigheder:	1066,1333,1600 Mhz
Ikke-bufferet hukommelse:	Ja
Antal SATA III-stik:	2
LAN Kontroller:	Realtek RTL8111E
Hukommelseskanaler:	Dual-channel
USB 2.0-stik:	2
USB 3.2 Gen 1 (3.1 Gen 1) stik:	1
CPU-ventilatorstik:	Ja
Antal COM-stik:	1
ATX strømstrik (24 stikben):	Ja
Antal kabinetventilatorstik:	2
Lydstik på frontpanel:	Ja
Antal SATA II stik:	4
Antal DVI-D-porte:	1
Motherboard form faktor:	micro ATX
Understøttede lagerdrev brugerflader:	SATA II,SATA III
Maksimal grafikadapterhukommelse:	1760 MB
BIOS-type:	AMI
BIOS-hukommelsesstørrelse:	64 Mbit
ACPI-version:	1.1
Wake-on-LAN klar:	Ja
RAID-niveauer:	0,1,5,10
Strømstik til ventilator:	Ja
PCI-slots:	2
Maksimalt antal SMP-processorer:	1
Grafikadapter familie:	Intel
