ASMB-585 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 ASMB-585 Startup Manual

• 1 Driver CD (user’s manual is included)

• 2 Serial ATA HDD data cables

• 2 Serial ATA HDD power cables

• 1 I/O port bracket

• 1 Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

ﬁle.Acrobat Reader can be downloaded at:

http://www.adobe.com/downloads/ (Acrobat is a

trademark of Adobe)

ASMB-585 Intel LGA1151 Xeon E3-1200 v5 /Core i3/i5/i7

series Micro ATX Server Board with 4 x PCIe slots, 6 x

USB3.0, 4 x GbE ports

Startup Manual

Standard SBC Functions

• CPU: Intel LGA1151 Xeon E3-1200 v5 /Core i3/i5/i7

series processors

• BIOS: AMI 128 Mb SPI BIOS

• Chipset: Intel®

C236

• System memory: Dual Channel DDR4 ECC/Non-ECC

1600/1866/2133 MHz unbuffered DIMM, Max. 64 GB

Note: Due to the inherent limitations of PC architecture,

the system may not fully detect 32 GB RAM

when 64 GB RAM is installed.

• SATA3 Interface: 7 SATA3 6Gb/s ports to support Intel

Matrix Storage with software RAID 0, 1, 10 & 5. (for

Windows only)

• Serial ports: Six serial ports, only supports RS-232

• Keyboard/Mouse connector: Supports standard PS/2

keyboard and mouse via KMBS1 pin header

• Watchdog timer: 255 level timer intervals (sec)

• USB 3.0: Supports up to Six USB 3.0 ports. Four ports

are in rear I/O, and two ports are on-board pin header.

• USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)

Display Interface

• Chipset: CPU integrated Intel HD graphics controller

• Display Memory: 1 GB maximum shared memory with 2

GB and above system memory installed

• Resolution:

- Supports RGB up to 1920 x 1200 resolution @ 60 Hz

refresh rate

- Supports DVI up to 1920 x 1200 resolution@ 60 Hz

refresh rate

Ethernet Interface

• Interface: 10/100/1000 Mbps

• Controller: LAN1:Intel

I219LM; LAN2 ~ LAN4: Intel®

I201AT

Mechanical and Environmental

• Dimensions (L x W): 244 x 244 mm (9.6” x 9.6”)

• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb

• Power consumption: Max. load: +3.3 V @ 17.57 A, +5

V @ 20.5 A, +12 V @ 16.74 A, +12 V (8P) @ 23.27 A, +5

Vsb @ 2 A, -12 V @ 0.3 A

• Operating temperature: 0 ~ 60° C (Depends on CPU

speed and cooler solution)

• Weight: 0.5 kg (weight of board)

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/applied-computing-

systems/

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/new_de-

fault.aspx

This manual is for the ASMB-585 series Rev. A1

Part No. 2001058511

Print in China

2nd Edition,

November 2015

2 ASMB-585 Startup Manual

Connector list

AUDIO1 Audio Connector

BH2 For optional battery kit

EX_THR1 For thermometer kit

SGPIO1, SGPIO2 Serial General Purpose I/O

JFP1 Power Switch / Reset connector

JFP2

External speaker / HDD LED

connector/ SM Bus connector

JFP3

Keyboard Lock and Power LED

Suspend: Fast ﬂash (ATX/ AT)

System On: ON (ATX/ AT)

System Off: OFF (ATX/AT)

SPDIF_OUT1 SPDIF Audio output pin header

Jumper list

Label Function

JCMOS1 CMOS clear

JME1

Intel ME Disable Jumper for ME/

BIOS update

JWDT1 Watch Dog Reset

JUSB1

Rear window USB2.0/3.0 port

power source switch between

+5 VSB and +5 V

JUSB2

On board USB2.0/3.0 port

power source switch between

+5 VSB and +5 V

CPUFAN_

SEL1,SYSFAN_SEL1

FAN PWM(1-2)/DC mode selec-

tion(2-3)

PSON1 AT(1-2) / ATX(2-3)

JCASE1 Case Open

JPEG1, JPEG2 x16 or x8x8 or x8x4x4

JGREEN1

Enable/Disable deep sleep

mode

JTHR_SEL1

To select on board or external

thermometer

The board has a number of jumpers that allow you to con-

ﬁgure your system to suit your application. The table below

lists the function of each jumper and connector.

Connector list

Label Function

ATXPWR1

ATX 24 Pin main power connec-

tor (for System)

ATX12V1

Processor power connector(for

CPU)

SATA0~6 SATA III (6Gb/s)

USB7_8, USB9_10,

USB11_12

USB 2.0 Port (Header)

USB13 USB 2.0 Port (USB Type A)

USB3_4 USB 3.0 Port (Header)

PCIEX4_SLOT4 PCIe p2-x4 slot (Gen3 p2-x4 link)

PCIEX4_SLOT5 PCIe p2-x4 slot(Gen3 p2-x1 link)

PCIEX16_SLOT6 PCIe x16 slot (Gen3 x16 link)

PCIEX4_SLOT7 PCIe p2-x4 slot(Gen3 p2-x4 link)

DIMMA0,DIMMA1,

DIMMB0,DIMMB1

DDR3 slot

CPUFAN0 CPU FAN connector

SYSFAN0,SYSFAN1,

SYSFAN2,SYSFAN3

System FAN connector

LAN1_USB1_2,

LAN2_USB5_6

LAN1 / USB 3.0 port 1, 2 stack

connector

LAN2 / USB 2.0 port 5, 6 stack

connector

LAN3_4 LAN3 & LAN4 connector

VGA1_COM1 VGA connector

DVI1_DVI2 DVI-D connector

KBMS1

External keyboard and mouse

connector(6 pin)

SPI_CN1 SPI ﬂash card pin header

LANLED1 LAN LED extension connector

SMBUS1 SM Bus From PCH

GPIO1 8-bit GPIO header

FPAUD1 Audio front panel header

COM2, COM3_4,

COM5_6

Serial port: RS-232

LPC1

Low pin count connector for

Advantech TPM LPC and

RS232/485 modules.

VOLT1 Voltage Display

Jumpers and Connectors Jumpers and Connectors (Cont.)
