Asrock H81M-ITX Manual

Asrock Bundkort H81M-ITX

Læs gratis den danske manual til Asrock H81M-ITX (80 sider) i kategorien Bundkort. Denne vejledning er vurderet som hjælpsom af 32 personer og har en gennemsnitlig bedømmelse på 3.7 stjerner ud af 16.5 anmeldelser. Har du et spørgsmål om Asrock H81M-ITX, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/80

User Manual

Version 1.0

Published August 2013

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Produkt Specifikationer

Mærke:	Asrock
Kategori:	Bundkort
Model:	H81M-ITX
Bredde:	- mm
Dybde:	- mm
Antal HDMI-porte:	1
HDCP:	Ja
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	4
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Digital akustisk og optisk udgang:	1
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Maksimal opløsning:	1920 x 1080 pixel
Hurtig installationsvejledning:	Ja
Kabler inkluderet:	SATA
Lyd-output kanaler:	7.1 kanaler
Certificering:	FCC, CE, WHQL\r\nErP/EuP
Strømkilde type:	ATX
Harmoniseret systemkode (HS):	84733020
Bæredygtighedscertifikater:	ENERGY STAR
Maksimal intern hukommelse:	16 GB
Mikrofonindgang:	Ja
S/PDIF-udgang:	Ja
Processorproducent:	Intel
Drivere inkluderet:	Ja
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Trusted Platform Module (TPM):	Ja
Komponent til:	PC
Kølingstype:	Passiv
Antal PS/2-porte:	1
Processor sokkel:	LGA 1150 (stik H3)
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ja
DirectX-version:	11.1
DVI dobbelt link:	Ja
Kompatibel processor serie:	Intel Celeron, Intel Pentium
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel® H81
Lydchip:	Realtek ALC892
Understøttede hukommelsestyper:	DDR3-SDRAM
Antal hukommelsesstik:	2
Hukommelses slots type:	DIMM
Ikke-fejlkorrigerende kode:	Ja
Understøttede hukommelsesclock-hastigheder:	1066,1333,1600 Mhz
Ikke-bufferet hukommelse:	Ja
Antal SATA III-stik:	2
LAN Kontroller:	Atheros AR8171
Hukommelseskanaler:	Dual-channel
USB 2.0-stik:	1
CPU-ventilatorstik:	Ja
ATX strømstrik (24 stikben):	Ja
Indbrudsttik til kabinet:	Ja
Antal kabinetventilatorstik:	1
Lydstik på frontpanel:	Ja
Antal DVI-D-porte:	1
Motherboard form faktor:	mini ITX
Understøttede lagerdrev brugerflader:	SATA III
Maksimal grafikadapterhukommelse:	1792 MB
BIOS-type:	UEFI AMI
BIOS-hukommelsesstørrelse:	32 Mbit
ACPI-version:	1.1
Wake-on-LAN klar:	Ja
Antal eSATA-porte:	1
Maksimalt antal SMP-processorer:	1
TPM-stik:	Ja
Grafikadapter familie:	Intel
PC sundhedsovervågning:	CPU, FAN, Power supply, Temperature
Diskret grafik support:	Ja
PCI Ekspres x16 (Gen 2.x) slots:	1
Intel® Core i3/i5/i7/i9 serie:	i3-4xxx, i5-4xxx, i7-4xxx
Påkrævet processor med Intel Graphics Technology:	Ja
