Side 1/146

Motherboard

P10S-M WS

Series

E13681

Revised Edition V4

December 2017

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

Offer to Provide Source Code of Certain Software

This product contains copyrighted software that is licensed under the General Public License (“GPL”),

under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software

Licenses. Such software in this product is distributed without any warranty to the extent permitted by the

applicable law. Copies of these licenses are included in this product.

Where the applicable license entitles you to the source code of such software and/or other additional data,

you may obtain it for a period of three years after our last shipment of the product, either

(1) for free by downloading it from https://www.asus.com/support/

(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location

where you want to have it shipped to, by sending a request to:

ASUSTeK Computer Inc.

Legal Compliance Dept.

15 Li Te Rd.,

Beitou, Taipei 112

Taiwan

In your request please provide the name, model number and version, as stated in the About Box of the

product for which you wish to obtain the corresponding source code and your contact details so that we

can coordinate the terms and cost of shipment with you.

The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as

the corresponding binary/object code.

This offer is valid to anyone in receipt of this information.

ASUSTeK is eager to duly provide complete source code as required under various Free Open Source

Software licenses. If however you encounter any problems in obtaining the full corresponding source

code we would be much obliged if you give us a notication to the email address gpl@asus.com, stating

the product and describing the problem (please DO NOT send large attachments such as source code

archives, etc. to this email address).

Produkt Specifikationer

Mærke:	Asus
Kategori:	Bundkort
Model:	P10S-M WS/IPMI-O
Bredde:	244 mm
Dybde:	244 mm
Wi-Fi:	Ingen
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Ethernet LAN:	Ja
Lyd-output kanaler:	8.0 kanaler
Harmoniseret systemkode (HS):	84733020
Maksimal intern hukommelse:	64 GB
S/PDIF-udgang:	Ja
Processorproducent:	Intel
Antal DisplayPorts:	1
Komponent til:	PC
Understøttet datalagringsdrev typer:	HDD & SSD
Processor sokkel:	LGA 1151 (stik H4)
Antal understøttede HHD'er:	8
Understøttelse af parallel behandlingsteknologi:	Ikke understøttet
Kompatibel processor serie:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium, Intel Xeon
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel® C236
Lydchip:	Realtek ALC1150
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	4
Hukommelses slots type:	DIMM
Understøttede hukommelsesclock-hastigheder:	2133,2400 MHz
Ikke-bufferet hukommelse:	Ja
Antal SATA III-stik:	8
Hukommelseskanaler:	To-kanals
USB 2.0-stik:	1
USB 3.2 Gen 1 (3.1 Gen 1) stik:	2
S/PDIF-udgangsstik:	Ja
CPU-ventilatorstik:	Ja
Antal COM-stik:	1
ATX strømstrik (24 stikben):	Ja
Anal EATX-strømstik:	1
Antal DVI-D-porte:	1
Motherboard form faktor:	micro ATX
Understøttede lagerdrev brugerflader:	M.2, SATA III
BIOS-type:	EFI AMI
BIOS-hukommelsesstørrelse:	128 Mbit
ACPI-version:	5.0a
Understøttede procesorsokler:	LGA 1151 (stik H4)
RAID-niveauer:	0, 1,5, 10
Strømstik til ventilator:	Ja
CD/AUX lyd, indgående:	Ja
PCI Ekspres x1 (Gen 3.x) slots:	1
PCI Ekspres x16 (Gen 3.x) slots:	1
TPM-stik:	Ja
Stik til frontpanel:	Ja
PCU Ekspres x4 (Gen 3.x) slots:	1
VGA-stik:	1
