Side 1/12
1 AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15A
AC Power Conditioner & Distribution
1601 Jack McKay Blvd. Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AP-S15A
AC Power Conditioner & Distribution Unit
AtlasSound.com 2
Specifications are subject to change without notice.
Owner’s Manual
AP-S15A
AC Power Conditioner & Distribution
1601 Jack McKay Blvd. Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Table of Contents
Important Safety Instructions .................................................................................................................. 3
Introduction ........................................................................................................................................... 5
Key Features and Applications 6 ...............................................................................................................
Front Panel Description ........................................................................................................................... 7
Rear Panel Description ............................................................................................................................ 8
Installation .............................................................................................................................................. 9
AC Power Cord Retainer System ........................................................................................................... 9
Specifications ....................................................................................................................................... 11
Warranty ................................................................................................................................................ 12
3 AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15A
AC Power Conditioner & Distribution
1601 Jack McKay Blvd. Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this device near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other device (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they
exit from the device.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the device. When a cart is used,
use caution when moving the cart/device combination to avoid injury from tip-over.
13. Unplug this device during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as
liquid has been spilled, or objects have fallen into the device, the device has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. WARNING: To reduce the risk of fire or electric shock, this device should not be exposed to rain or moisture and objects filled with
liquids, such as a vase, should not be placed on this device.
16. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle.
17. The mains plug of the power supply cord shall remain readily operable.
The lightning flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage “ within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
AtlasSound.com 4
Specifications are subject to change without notice.
Owner’s Manual
AP-S15A
AC Power Conditioner & Distribution
1601 Jack McKay Blvd. Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
When The Device Is In Use
To prevent electric shock, do not remove the product cover as there are high voltage components inside. Refer all servicing to
Atlas Sound.
Should any of the following irregularities occur during use, immediately switch off the power, disconnect the power cord from the
AC outlet and contact Atlas Sound. Do not to attempt to continue operation with the product as this may cause fire or electric shock:
Smoke or strange smell coming from the unit.
If the product falls or the case is damaged.
If water or any metallic objects falls into the product.
If the power supply cord is damaged in any way.
If the unit is malfunctioning.
Do not insert or drop metallic objects or flammable materials into the ventilation holes of the product's cover, as this may result in
electric shock or fire.
Do not place any containers with liquid or metallic objects on the top of the product. If any liquid spills into the unit, fire or electric
shock may result.
Never operate this product or touch the power supply cord during an electrical storm, electric shock may result.
Never exceed the power rating on the product when connecting equipment. Fire and/or property damage may result.
Operate the product only with the voltage specified on the unit. Fire and/or electric shock may result if a higher voltage is used.
Do not modify, kink, or cut the power cord. heavy objects Do not place the power cord in close proximity to heaters and do not place
on the power cord, including the product itself, doing so may result in fire or electrical shock.
Ensure that the safety ground terminal is connected to a proper ground. Never connect the ground to a gas pipe as a catastrophic
disaster may result.
Be sure the installation of the product is stable, avoid slanted surfaces as the product may fall and cause
injury or property damage.
When Installing The Product
Plugging in or unplugging the power cord with wet hands may result in electric shock.
Never move the unit with the power cord plugged into the wall, as damage to the power cord may result.
When unplugging the cord from the wall, grasp the plug, NOT the cord.
Never install this product in humid or dusty locations, nor in direct sunlight, near sources of heat, or in areas where sooty smoke or
steam are present. Fire and electric shock may result.
Keep all sides of the unit at least 3
1 " away from objects that may obstruct air flow to prevent the unit's internal temperature rise.2
When The Product Is In Use
Never place heavy objects on the product, causing it to fall and/or break, resulting in personal injury and property damage. In
addition, the product itself may fall and cause injury and property damage.
result in heat Contact Atlas Sound for instructions on cleaning the inside of the unit. Large accumulations of dust inside the unit may
buildup and fire.
Ensure that the power supply plug is securely plugged into the wall outlet. Never allow dust to accumulate on the power plug or
inside the wall outlet.
When cleaning the unit or the unit is not to be operated for an extended period, unplug the power cord from the wall.
CAUTION
WARNING
CAUTION
5 AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15A
AC Power Conditioner & Distribution
1601 Jack McKay Blvd. Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Introduction
Thank you for purchasing the Atlas Power AP-S15A AC Power Conditioner & Distribution Unit. The AP-S15A has been designed to
meet most installation requirements for AC power distribution and equipment power protection.
The AP-S15A features noise filtering for unwanted Radio Frequency Interference (RFI) that is commonly introduced into AC lines by
nearby radio transmitters or wireless products. EMI filters are incorporated to reduce noise from Electromagnetic Interference (EMI)
from such items as electric motors and switching power supplies. The benefit of these filters can be seen on video products or audibly
by reducing static pops and external signal interference.
The AP-S15A is unique in that the integrator can select the power cord length that is required for the installation. A removable 12' IEC
power cord with a retainer bracket is supplied with the unit. A shorter or longer cord can be purchased separately if needed.
Unstable AC Mains voltage is one of the main reasons for equipment failure. The amount of energy that can be injected into the power
system can be immense with voltages reaching 6kV or amperage peaks of 3000A. These spikes are very fast and usually only last for
a very short period of time. The AP-S15As circuitry is very fast and can suppress unwanted energy within a nanosecond response and
sustain the suppression up to 2 milliseconds, thus ensuring virtually trouble free protection. The front panel also features AC fault and
ground status indicators providing quick, visual reassurance the equipment is safe.
The AP-S15A offers power management control, noise filtering, and spike/surge protection, making it the most compact, effective
power management protection system on the market today.
7 AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15A
AC Power Conditioner & Distribution
1601 Jack McKay Blvd. Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Front Panel Features
1. Unswitched AC Outlet
The 120VAC outlet is always live when the AP-S15A power cord is plugged into an AC mains power source. The AC mains Note:
power switch does not affect the Unswitched AC Outlet but it is protected with surge protection circuitry.
2. Power Switch & Cover
To turn the AP-S15A On or Off, press the switch to the On or Off position. When in the On position and AC voltage is present the
power LED will illuminate. The AP-S15A incorporates a power switch cover to prevent accidental pressing of the power switch.
3. Switched Outlets Active Indicator
This LED will illuminate Blue when the power switch is in the On position.
4. Surge Protect Indicator
The Surge Protect LED is illuminated under normal operating conditions showing that the surge protection circuit is functioning
correctly and the connected equipment is protected from voltage transients. Although the clamping suppression circuit virtually assures
protection from most transient voltage spikes and surges, nature has a way of occasionally creating electrical forces that are beyond
the capabilities of any device to absorb without some degree of damage. In the rare instance that this occurs and the circuit has been
damaged, the Red Surge Protect” LED indicator will turn off. The AP-S15A will shut off permanently until the unit is repaired. Be
advised that activation of this fault condition and the associated repair is not covered under warranty. If the Surge Protect LED is Note:
not illuminated while the unit is powered on, it is important to have all equipment that was connected to that AC Mains Line inspected
for proper operation.
5. Ground Status Indicator
This LED will illuminate Green when the AP-S15A has Earth ground connection on the Earth ground pin of the AC Mains power cord.
Note: If there is no Earth ground connection the LED will not illuminate and the AC wall outlet must be repaired by a qualified electrician
before continuing.
12 3
4
5
AtlasSound.com 8
Specifications are subject to change without notice.
Owner’s Manual
AP-S15A
AC Power Conditioner & Distribution
1601 Jack McKay Blvd. Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Rear Panel Features
1. AC Mains Input
Connect the IEC 14 Gauge 12' (4m) power cord to a 15A 120VAC outlet to provide power to the AP-S15A.
2. AC Mains Input IEC Power Cord Retainer
The AP-S15A incorporates an IEC power cord retainer bracket to prevent the cord from coming loose. See IEC power cord retainer
bracket installation.
3. AC Mains Power Breaker
The 15A rated breaker will open if the combined draw of all AC outlets exceeds 15A. The breaker is designed to exceed its rating Note:
for a short period of time. If the breaker is tripped, the load must first be removed from the AP-S15A before pushing to reset.
4. Unswitched AC Outlet
The 120VAC outlet is always live when the AP-S15A power cord is plugged into an AC mains power source. The AC mains Note:
power switch does not affect the Unswitched AC Outlet but it is protected with surge protection circuitry.
5. Switched AC Outlets
The seven 120VAC outlets are always live when the AP-S15A front panel power switch is in the On position.
1 2345
