Side 1/12
Owner’s Manual
TSD-ZDC
Audio Impedance Combiner/Divider
AtlasSound.com – 1 –
Specifications are subject to change without notice.
*ACK-C+AY"LVDs%NNIS4EXAS53!
4ELEPHONEs&AX
TSD-ZDC
Audio Impedance Combiner/Divider
Owner’s Manual
TSD-ZDC
Audio Impedance Combiner/Divider
AtlasSound.com – 2 –
Specifications are subject to change without notice.
*ACK-C+AY"LVDs%NNIS4EXAS53!
4ELEPHONEs&AX
Description
The Atlas Sound TSD-ZDC is a universal impedance divider/combiner for passively summing or
splitting of mic or line level signals. Features include four balanced 10K and four balanced 1501 1
inputs/outputs that may be passively split or combined in any arrangement.
Typical applications include:
Ê UÊ *>ÃÃÛiÊÃÕ>ÌÊvÊÕÌ«iÊ£xä1 1 mics or stereo 10K sources
Ê UÊ *>ÃÃÛiÊëÌÌ}ÊvÊ£xä1 1 or 10K input sources to multiple outputs
The TSD-ZDC is part of a full line of Atlas Sound Time Saving Devices. These compact
(1.5" x 4" x 2.75") units are designed to solve some of the common audio system problems in the
easiest and in the most efficient and cost-effective way. All models are made from high quality
components and include removable individual I/O connectors for quick and precise wiring, separate
ground terminals for all I/Os assuring secured connections, and allows easy standalone mounting
with either included Velcro/mounting brackets or can be rack mounted with an optional rack adapter
kit that can hold up to four TSD devices in a 1RU space.
Features
Ê UÊ 1 In x 3 Out, 2 In x 2 Out, 150 Input/Outputs1
Ê UÊ 1 In x 3 Out, 2 In x 2 Out, 10K Input/Outputs
Ê UÊ Split or Combine Any Signal
Ê UÊ RF Filtering on All Inputs
Ê UÊ Individual Input Grounds
Ê UÊ ,iÛ>LiÊÉ"ÊiVÌÀÃ
Ê UÊ ÊÝÌiÀ>Ê*ÜiÀÊ,iµÕÀi`
Ê UÊ «>VÌÊ>ÃÃÃÊiÃ}
Audio Applications
Ê UÊ LiÊÕ«ÊÌÊÎÊVÀ«iÃÊÌÊ"iÊ"ÕÌ«ÕÌ
Ê UÊ Û`iÊ>Ê-}iÊVÀ«iÊ-}>ÊÌÊ/ÀiiÊVÊ"ÕÌ«ÕÌÃ
Ê UÊ LiÊ-ÌiÀiÊ-}>ÃÊÌÊ>ÊÊ-}>
Ê UÊ Û`iÊ>ÊÊiÊiÛiÊ-}>ÊÌÊ>Ê-Õ>Ìi`Ê-ÌiÀiÊ-}>
Ê UÊ ``Ê>Ê<i
Installation
Ê UÊ ÛiÀiÌÊLÕ`}Ã
Ê UÊ i`V>Ê>VÌiÃ
Ê UÊ "vwViÊÛÀiÌÃ
Ê UÊ ÕÀViÃ
Ê UÊ ,iÃÌ>ÕÀ>ÌÃ
Ê UÊ -VÃ
Ê UÊ `ÕÃÌÀ>Ê>VÌiÃ
Ê UÊ ÕÃiÊvÊ7ÀÃ«
