Side 1/6

1

Installation Guide

AT-VTP-FMK-10-BL

Flush Mount Kits for Velocity Touch Panels

AT-VTP-FMK-10-BL

The Atlona AT-VTP-FMK-10 is a ush mount kit for Velocity™ 10” touch panels. It allows the

touch panel to be recessed into a wall so the panel face is virtually ush with the wall surface.

The VTP-FMK-10 kit fastens to the wall with adjustable metal tabs and the touch panel attaches

to the mount via four magnets. These magnets secure the touch panel to the enclosure when in

use while also allowing it to easily be removed for maintenance if necessary. The VTP-FMK-10

is available in black and compatible with Velocity 10” touch panels including the AT-VTP-1000VL

and AT-VTPG-1000VL.

1 x AT-VTP-FMK-10-BL

1 x Perforated Wall Cutout Template

4 x Magnets

4 x Plastic Washers

4 x Screws

Package Contents

2

Installation Guide

AT-VTP-FMK-10-BL

Mounting Instructions

Use the following steps to install the AT-VTP-FMK into the wall.

1. Remove the inner two cut outs from the Perforated Wall Cutout Template. Just the outer ring

should remain.

10” Cutout Ring

8.09 inch

205.5 mm

10.71 inch

272 mm

5.41 inch

137.5 mm

7.76 inch

197 mm

8.09 inch

205.5 mm

5.41 inch

137.5 mm

10.71 inch

272 mm

7.76 inch

197 mm

2. Trace the inside edge of the cutout ring onto the wall.

3. Cut and remove the traced part of the wall.
