Kramer Electronics, Ltd.

Preliminary

USER MANUAL

Model:

VS-88HDxl

8x8 3G SD/HD-SDI Matrix Switcher

Contents

1 Introduction 1

2 Getting Started 1

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 3

2.4 Quick Start 3

3 Overview 5

4 Your VS-88HDxl 8x8 3G SD/HD-SDI Matrix Switcher 6

4.1 Using the IR Transmitter 9

5 Installing the VS-88HDxl in a Rack 10

6 Connecting the VS-88HDxl 11

6.1 Connecting the VS-88HDxl in the Single Link Mode 11

6.2 Connecting the VS-88HDxl in the Dual Link Mode 13

6.3 Setting the Working Mode 15

6.4 Connecting the RS-232 Port 15

6.4.1 Determining the Machine Number 15

6.4.2 Setting the DIP-Switches 16

6.5 Connecting a PC or Controller to the RS-485 Port 17

6.5.1 Setting the Address Switches 17

6.5.2 Setting the Line Termination 17

6.6 Switching Genlocked Video Signals 18

6.7 Connecting the Ethernet Port 18

6.7.1 Connecting the ETHERNET Port Directly to a PC (Crossover Cable) 18

6.7.2 Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 20

6.8 Configuring the Ethernet Port 20

6.9 Controlling via the Ethernet Port 20

6.10 Using the Ethernet Reset Button 20

7 Operating the VS-88HDxl 20

7.1 Operating the VS-88HDxl from the Front Panel 21

7.1.1 Power On Display 21

7.1.2 Using the AT ONCE and CONFIRM Modes 21

7.1.3 Switching in the AT ONCE Mode 21

7.1.4 Toggling Between Modes 21

7.1.5 Switching in the CONFIRM Mode 22

7.1.6 Storing an Input/Output Configuration 22

7.1.7 Recalling an Input/Output Configuration 22

7.1.8 Locking the Front Panel 23

7.1.9 Switching Protocols 23

7.1.10 Indicating Errors 23

7.2 Using Serial Commands 23

Produkt Specifikationer

Mærke:	Kramer
Kategori:	Router
Model:	VS-88HDxL
Vægt:	2600 g
Produktfarve:	Sort
Indgangsspænding for vekselstrømsadapter:	100 - 240 V
Frekvens for vekselstrømsadapter:	50/60 Hz
Kabler inkluderet:	Vekselstrøm
Fjernbetjening inkluderet:	Ja
LED-indikatorer:	Ja
Harmoniseret systemkode (HS):	85176990
Fjernbetjeningstype:	IR
Video porttype:	BNC
BNC-indgangsporte:	8
BNC porte, udgående:	8
