ATOLL ELECTRONIQUE
OWNER’S MANUAL ~ CD DRIVE
DR100 EVO - DR200 EVO
ATOLL ELECTRONIQUEPage 5Page 4
Keys 8 to 13 have the same functions as on the front panel.
19) REPEAT Mode (This function is also available while reading the disc)
Press on REP to choose the repeat mode:
— R1: makes a repetition of the same track. Confirm by pressing the ENTER key. The
display shows R1 between the number and the time of the track.
— R: makes a repetition of the complete disc. Confirm by pressing the ENTER key. The
display shows R between the number and the time of the track.
STOP key (and keys 7) previous track & 8) next track on R1 mode) cancels also all
REPEAT modes.
20) PROGRAM (PROG.):
— Press on PROG. The display shows on the Left the number of selected tracks (Nb 0)
and on the Right the choice of tracks (Tr 1).
— Choose the first track of the program with the selection keys 8 & 9. Confirm
by pressing on PROG. Select all tracks needed for the program, using the same
procedure.
— The display shows the number of tracks (on the Left), P symbol. The total time of the
program is seen by a press on TIME. Press PLAY to start playing the program.
— Press 2 times to cancel the program.
21) SHUFFLE: Press on SHUF. The display shows S between the number and the time of
the track. The disc goes on the play. All tracks will be played once in random mode. Press
STOP to cancel the random play.
SHUFFLE and PROG menus are not available while reading the disc.
Combination: it is possible to combine a program with the REPEAT function (display shows
RP) and SHUFFLE functions (display shows RS).
22) DISP.: allows to switch off the display.
14) TIME: Displays the running time of each track.
With one press, display the remaining time of the
track.
15) Inactive.
16) Rear fast search key.
17) Forward fast search key.
18) A-B repeat: allows to select a specific reading
zone from point A to point B. While playing, press
this key to start the beginning of zone A, press a
second time to select the end B. Selected zone will
be played until you press again the AB key.
7) Disc tray.
8) Previous track.
9) Next track.
10) Open/close.
11) Pause & Play.
12) Stop: stop functions Play & Repeat.
13) ON/STANDBY key: this key cancels
all functions.
CONNECTING REMOTE CONTROL
DETAILS OF FUNCTIONS
1 2 3 654
1) Coaxial output (to a converter D/A).
2) Optical output (to a converter D/A).
3) AES/EBU output (only for DR200).
4) Trigger output 12V.
5) Mains socket.
6) ON/OFF power switch.
8 9 10 11 12 13
7
22
13
17
9
21
11
14
16
8
19
15
12
18 20
10
10
