*Subject to change without notice Atomos Ninja Inferno – User Manual Edition 1: May 2017 1

ATOMOS NINJA INFERNO

USER MANUAL

EDITION 1: MAY 2017

Have you registered your Ninja Inferno yet?

Upgrade to 3 year warranty now

Web: www.atomos.com Sales: sales@atomos.com Support: www.atomos.com/support

*Subject to change without notice Atomos Ninja Inferno – User Manual Edition 1: May 2017 2

Warranty & Conditions 3

Introduction 4

 1.What’sincluded 5

2. What you also need 6

Spinning Disk Drives (HDD) 6

Solid State Drives (SSDs) 6

Mechanical Shock and Vibration 6

Backing up and archiving 7

HDMI Cables 7

3. Mounting disks in the Master Caddy II 8

4. Connecting and powering up 9

Power ON/Power OFF 10

 5.NinjaInfernoconnections 11

6. Master Caddy II, Screw Mounts and Sun Hood 13

Master Caddy II / Screw Mounts / Modularity 13

Sun Hood 14

 7.UsingtheNinjaInferno 15

Using the Ninja Inferno 15

Category 1: Operating Settings 15

Category 2: Shot Setup & Monitor Tools 15

Category 3: Main Controls, REC, PLAY & MENU 15

Home Screen / Menu functions 16

File Naming / Date & Time / Display Options 17

Screen lock / Timecode / Ninja Inferno Info 18

Input Menu 19

Storage Capacity Indicator / Formatting HDD/SSD / Unit Name 20

Audio panel 21

8. Monitoring and Recording 22

Before recording / Choosing your recording format 22

SmartControl / 6 ways to start recording 23

Waveform Monitoring 24

Luma Overlay / RGB Parade / Vectorscope 25

Monitor Assist 26

Focus Assist / Zebra / False Color 27

Blue Only / Grid Lines / Focus Assist Settings 28

SmartLog 29

Exporting .xml 30

Monitor mode (HDR / Log / Custom Looks) 31

Anti-shock technology 35

File Recovery 35

9. Timecode 36

LTC / Record Run / Auto Restart 37

10. HD Pulldown 38

11. Record mode options 39

12. Playback & Playout 41

13. Connecting and Editing 43

Connect to Input 43

NLE Support 43

exFAT compatibility 43

  Transferringles 43

Importing / Import into Final Cut Pro 44

SmartLog with FCPX 45

14. Software Upgrades 46

Updating AtomOS (Firmware) 46

 15.TechnicalSpecications 47

Contents Safety Instructions

User Manual Conventions

The Ninja Inferno is designed to a high standard but there are some

things you should be aware of to prolong the life of the unit and for

your own safety.

Using the Ninja Inferno safely

Although the Ninja Inferno is very lightweight compared to all the devices it

replaces, it is still a solid object that could cause injury if misused.

• Always make sure that the Ninja Inferno is mounted securely and is

unable to fall onto anyone nearby. This is especially important when

there are children present who might be tempted to pull on cables.

• Always ensure that cable runs to the Ninja Inferno are clearly visible and

do not present a trip hazard.

• Do not place on uneven or unstable surfaces.

• Do not insert anything but Ninja Inferno Master Disk caddies in the

Master Disk slot on the front of the Ninja Inferno.

• Do not touch the Ninja Inferno’s screen with sharp, metallic or abrasive

objects.

• Donotexposetostrongelectricalormagneticelds.

• Do not expose to or use near liquids, rain or moisture.

• Do not dispose of the Ninja Inferno in municipal waste and do not incinerate

it, always follow local regulations for safe disposal.

Care of disk drives

Spinning disks and SSDs are very sensitive to damage from static electricity.

Please observe all the usual ESD precautions when handling them.

Please see the section Mechanical shock and vibration later in this manual

for information about how to handle and care for your disk drives.

HDMI cables

Please remember that HDMI cables do not use locking connectors and will

simply pull out if they are jerked or tripped over. Please ensure your cables

makeasecureconnectionandavoidexingthemexcessivelytomaintain

reliability.

Tokeepthingssimplebutclear,we’veonlyadoptedtwoconventions

in this manual:

A helpful tip, suggestion or something to note because it’s not

obvious at rst.

An important note or warning

Produkt Specifikationer

Mærke:	Atomos
Kategori:	Ikke kategoriseret
Model:	Ninja Inferno
Vægt:	630 g
Produktfarve:	Sort
Skærmopløsning:	1920 x 1200 pixel
Antal HDMI-porte:	2
Skærm:	7.1" IPS
Dimensioner (BxDxH):	214 x 127 x 45 mm
Hurtig start guide:	Ja
AC-adapter inkluderet:	Ja
Maksimal videoopløsning:	3840 x 2160 pixel
Maksimum billedhastighed:	100 fps
Indbygget processer:	Ja
Optisk drev inkluderet:	Ingen
