MANUAL
Table of Contents
9
1. Parameters.................................................................................................................1
2. Safety use cautions...................................................................................................1
3. Contents in the package.........................................................................................1
4. Communication cable.............................................................................................1
5. DMX512 address distribution....................................................................................2
6. Diagram of the communication cable link and scanner address set.................3
7. Diagram of the panel and functional areas..........................................................4
8. Explanation of functional area of the panel..........................................................4
9. Explanation of the duplex key area........................................................................5
10. Explanation of the display information on the LCD.............................................6
11. The editing of scanner chase.................................................................................7
12. Running of scanner chases....................................................................................7
13. Special scene presentation...................................................................................8
14. How to set and cancel the joystick potentiometer.............................................8
15. Conventional dimmer control...............................................................................9
Cancel rocker potentiometer settings: In the state of [SET X/Y], press [DELETE] to
clear the input data, and the green indicating light turns off immediately; and
then press [SET X/Y] again to memorize it and quit.
15. Conventional dimmer control
Point control: Press P13-P24 to control the dimmer 206-217 channels, and when
the indicating light is on, the output is 100%, and when the indicating light is off,
the outputs is 0%.
Distributed control: In the state of non-programming, press SCAN/LIGHT to
make the indicating light turn on; enter the dimmer state, select the channel
page of dimmer control by pressing SA/SB/SC, and push the different sliders in
the slider area to adjust the dimmer output.
