The DQ-61 is your gateway to amazing

sound from a factory head unit. It is a com-

pact six channel, high-performance, line level

converter with independent multi-channel

equalization and signal delay to custom tune

the system. AudioControl’s patent

pending AccuBass® system corrects

for the factory bass roll-off present in

so many of today’s cars. In short; the

DQ-61 can make every car sound its

very best.

Here are some of the unique features of the AudioControl DQ-61:

• User friendly Signal Delay to control the acoustical alignment between the

left and right channels the front and subwoofer channels plus

• Individual equalization controls for the front, rear and subwoofer channels

for simple yet precise system tuning

• Six channels of active speaker level inputs – accept up to 400 watts per

channel

• AccuBASS™- AudioControl’s patented pending processing to correct the

bass roll-off in factory source units

• ACR-3 Dash Control Remote allows for control of the subwoofer level plus

processing bypass

• Internal Channel Summing – Easy interface with factory installed ampli-

ers with built-in crossovers

• Discrete Input and Output level controls

• GTO™ signal sensing inputs (selectable) to turn the DQ-61 on automati-

cally and give you a 12 volt trigger to turn on your amplier

• Bulletproof 5 year warranty (when installed by an authorized AudioControl

dealer)

®Making Good Sound Great®

If you are a seasoned audio enthusiast and are chomping at the bit to begin

your experience with the DQ-61, we offer some Quick Install Guidelines below

to help maximize your experience. Please refer to the system diagrams on page

8 as good guidelines.

1 Physically mount the DQ-61 in a location that keeps it away from bever-

age spills, food crumbs, and curious ngers. You will want to select a location

that allows you access to the top panel controls. In many cases you can nd

factory speaker leads in the rear of the vehicle or at the factory amplier that

are easy to access.

2 The DQ-61 needs to be installed in the signal path between your OEM

source unit (or factory amplier) and an after-market amplier and/or

processor(s). Do not connect the DQ-61 between the factory head unit and

the factory amplier. Locate the amplied speaker wires that are coming from

your factory source unit and/or amplier and connect them to the speaker-level

inputs on your DQ-61.

Note: If your source unit has front, rear, and subwoofer speaker-level out-

puts, connect them to the three sets of inputs on your DQ-61. If the source unit

only has front and rear outputs, the Auto Mode circuitry in your DQ-61 auto-

matically routes the Channel 2 input channels to the (Channel 3) subwoofer

channels.

3 Use RCA connecting cables to connect the RCA outputs of the DQ-61 to

your after market amplier(s). If this is not obvious to you, quickly pack up

your DQ-61 and run to your nearest authorized AudioControl dealer to have

them perform the installation. You will thank us later.

4 Connect +12 volt power, ground and turn-on wires as needed. Don’t forget

the fuse! Note: The DQ-61 has a 12-volt trigger input but normally you will

just let the GTO turn on circuit take care of that by itself.

5 Connect your amplier trigger input to the 12-volt trigger output of the

DQ-61

6 Turn your amp gains fully down before turning on the system.

7 Turn on the system and level match your DQ-61 to your source unit and

ampliers.

8 On the chassis of the DQ-61, set to . Signal Delay Mode Set-Up

9 Using the Dash Control, adjust the signal delay between the Left and Right

channels for optimum sound. Check out our YouTube video for assistance.

0 Tap the ACR-3 Dash Control and adjust the signal delay between the front

and subwoofer outputs.

On the chassis, change to .Signal Delay Mode Normal

page 2
