Side 1/2
When to Replace Filters
Filter Indicator Light When to Service When to Replace
Pre-Filter none PermanentClean once every 14 days
Deodorization Filter none
Can NOT be WASHED
Every 3 months
True HEPA Filter
Lasts up to
12months
• Intervals between filter replacement may vary depending on environment.
MAINTENANCE
INITIAL OPERATION
REPLACING FILTERS
Resetting Filter Life:
After replacing your True HEPA Filter, place the Pre-Filter back in and close the Front Panel.
While the unit is on, hold the Filter Reset Button for at least 5 seconds until you hear the beep.
After the beep, the Filter Replacement Indicator will disappear. The True HEPA Filter is now reset.
1.
Remove the front panel by grasping its upper edge
and gently pulling forward.
2.
Remove the Pre-Filter, then the bag of filters behind
it.
3.
Remove filters from protective plastic bag.
4.
Install the filters until they fit securely in place.
03. True HEPA Filter (back)
02. Activated Carbon Filter (middle)
01. Pre-Filter (front)
5.
After filters are installed, close the front panel.
6.
Insert the power cord into an electrical outlet.
Latch
01
02
03
Latch
FRONT
PACKAGE CONTENTS
BACK
Control Panel
Front Panel
Air Outlet
Vent
Handle
Power Plug
Unit
(1) Pre-Filter
(8) Activated Carbon Filters
(2) True HEPA Filters
Wi-Fi Setup Guide
User
Manual
WHERE TO USE
MODEL PART DIAGRAM
30~45cm
30~45cm
Allow 30~45cm. of space between TVs, radios, and
other electronics.
Electromagnetic interference from
certain electronics may cause product malfunction.
Place indoors away from direct sunlight.
Direct
exposure may cause product malfunction or failure.
Only place on hard, flat surfaces.
Flimsy or slanted
surfaces may result in abnormal noise and vibrations.
Allow at least 30~45cm. from walls for maximum air
flow
3
True HEPA Filter
2
Activated Carbon Filter
4
PlasmaWave® TechnologyPre-Filter
1
4-STAGE AIR PURIFICATION
Air Purification means it
removes inanimate particles
01. Auto Mode Indicator - The LED "Auto"
light will indicate when Auto Mode is
activated.
02. Air Quality Indicator - Color coded LED
light indicates one of three levels of Air
Quality: Red (poor), Amber (fair), and Blue
(good).
03. Fan Speed Indicator - Indicates the
current fan speed.
04. Sleep Mode Indicator - The LED "Sleep"
light will indicate when Sleep Mode is on.
05. Filter Replacement Indicator - LED light
indicates when it is time to change the filter.
06. Filter Reset Button - After replacing the
True HEPA Filter, use a small object such as a
paper clip, to press and hold the Filter Reset
Button for at least 5 seconds until the Filter
Replacement Indicator turns off.
07. Smart Sensor - Detects the amount of
odorous gas in the environment. When in
Auto mode, the fan speed adjusts according
to the detected amount of gas.
08. Power Button -
Turns the unit on or off.
During the first 30 seconds of powering up,
the Air Quality Indicator will cycle through
Blue, Amber and Red colors.
• Smart sensor takes approximately 4 minutes
to detect the air quality in the environment
before normal operation begins.
09-1. Fan Speed/Auto/Sleep Buttons -
Use
the Fan Speed arrow buttons to set the
desired fan speed. Fan Speeds cycle over
in this sequence: Auto, Low, Medium, High,
Turbo, Sleep, Auto.
Auto Mode:
Automatically adjusts fan speeds
according to your indoor air quality. The fan
speed will adjust to low when air quality is
good, medium when fair, and to high when poor.
Sleep Mode: When Sleep Mode is activated,
the Air Quality Indicator LED light is disabled.
• Fan speed will automatically set to minimum
speed (lower than 'Low') which will be
nearly silent. When Sleep Mode is active,
PlasmaWave
®
will be disabled, but it can be
turned back on.
09-2. PlasmaWave
®
Button - Press and hold
the buttons
+
for 3 seconds
Press the Plasmawave
®
button when the unit
is on to enable or disable this feature. By
default, PlasmaWave
®
is enabled whenever
the unit is powered on. When the unit is
running, you may hear a chirping or buzzing
sound. The sound is from particles passing
through PlasmaWave
®
, it is normal and does
not signify product failure.
10. PlasmaWave
®
Indicator - Indicates
whether PlasmaWave
®
is enabled or disabled.
11. Wi-Fi Button -
Press for 3 seconds to
activate pairing mode. When Wi-Fi is paired,
press the button to turn Wi-Fi off or back on.
12. Wi-Fi Indicator -
Enables or disables the
Wi-Fi feature. When in the pairing state, the Wi-
Fi LED flashes. When paired successfully, the
Wi-Fi LED will be a solid white light.
13. Light Sensor - Detects the amount of
ambient light in the environment. When in
Auto Mode, the light sensor detects when to
put the unit into Sleep Mode.
Winix Smart Wi-Fi Setup - Refer to the Wi-Fi
Guide provided inside the box.
CONTROL PANEL
07 08 09 11 13
02 03 04 05 0601
1210
CLEANING CARE
Cleaning the Filters:
Use a vacuum cleaner or soft brush to
clean the Pre-Filter.
• If it is excessively soiled, rinse in room
temperature water. Do not use detergent or
soap.
Allow the filter to dry for 24 hours or
more before using.
Intervals between filter
cleaning may vary depending on the air
quality. Do not use hot water over 40
o
C or
volatile fluids such as paint thinner.
Cleaning the Exterior & Interior:
Wipe with a soft damp cloth using room
temperature water.
• Afterwards, wipe it down with a dry cloth.
Open the front panel and clean the interior
with a vacuum cleaner.
• For optimal performance, clean every
1-2months.
N O T I C E
• When cleaning the unit, always unplug the power cord
first and then wait until the unit has cooled down.
• Never disassemble, repair, or modify this unit yourself.
• Do not use flammable sprays or liquid detergents.
• Do not allow children to clean or maintain the unit.
• Before cleaning or maintaining, ensure unit is
unplugged.
• Do not use benzene, alcohol, or other volatile fluids,
which may cause damage or discoloration
.
SPECIFICATIONS
Model C545(AU)
Voltage AC 220 V - 240 V, 50 / 60 Hz
Power Rate 65 W
Dimensions
350 mm (W) x 215 mm (D)
x 524 mm (H)
Weight 5 kg
Filter SKU Filter GA : 1712-0096-12
Exterior design, and product specifications may be changed
without prior notice to improve product performance.
AUSCLIMATE FILTER CLUB
For exclusive savings on replacement filters ausclimate.com.au/pages/filter-club
New Zealand
PO Box 100707
North Shore Mail Centre
Auckland 0745
www.cdbgroup.com
Australia
PO Box 574
South Morang
Victoria 3752
www.cdbgroup.com
SAFETY AND CAUTIONS
Before operating this equipment, carefully read and
follow these safety cautions.
Ensure filters are inserted before running unit. Running
the unit without filters can shorten the lifespan of the
unit and cause electric shock or injury.
Be sure foreign objects are NOT inserted into the vents
on the unit. Objects can include pins, rods, and coins.
Do not touch any part of the interior of the unit with wet
hands. The high voltage may cause electric shock.
Ensure unit intake and outlet vents do not become
blocked. Blockage may lead to increased internal
termperatures, causing product failure and deformation.
Do not use the unit as a step stool or place heavy
objects on the unit. Personal injury may occur or
product failure and deformation.
W A R N I N G
Follow these instructions to reduce
the risk of serious injury or death and
to reduce risk of damaging the unit.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
This appliance can be used by children aged
from 8 years and above under supervision.
This appliance can be used by persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
Children should be supervised to ensure that
they do not play with the appliance.
• Do not repair or modify the unit. All repairs
should be completed by a qualified technician.
• Do not use if the power cord or plug is
damaged or the connection to the wall outlet
is loose.
• Use AC 220 - 240 V only.
• Do not damage, break, forcefully bend, pull,
twist, bundle, coat, pinch, or place heavy
objects on the power cord.
• Periodically remove dust from the power plug.
This will reduce the risk of shock due to
humidity build up.
• Remove the power plug from the outlet before
cleaning the unit. When removing the power
plug, grasp by holding the plug itself, never
hold by the cord.
• If the power plug is damaged, it must be
replaced by the manufacturer or a qualified
technician.
• Remove the power plug from the outlet when
not in use.
• Do not handle the power plug with wet hands.
• Do not operate the unit when using indoor
smoke-generating insecticides.
• Do not clean unit with benzene or paint
thinner.
Do not spray insecticides on the unit.
• Do not use the unit where it is humid or
where the unit may become wet, such as the
bathroom.
• Do not insert fingers or foreign objects into air
intake or outlet.
• Do not use the unit near flammable gases.
Do not use near cigarettes, incense, or other
spark-creating items.
• Unit will not remove carbon monoxide emitted
from heating appliances or other sources.
• Unplugging the product disconnects the
remote functions.
IMPORTANT PRECAUTIONS FOR USING YOUR
AIR PURIFIER:
• Do not block the intake or outlet vents.
• Do not use near hot objects, such as a stove.
• Do not use where the unit may come into contact
with steam.
• Do not use the unit on its side.
• Keep away from products that generate oily
residue, such as a deep fryer.
• Do not use detergent to clean the unit.
• Do not operate without a filter.
• Do not wash and reuse the True HEPA Filter.
• Hold the handle on the back of the unit to
transport.
• Do not hold by the front panel.
• Do not stick any small objects into the air
outlet vents or fan.
IMPORTANT CAUTIONS FOR USING YOUR AIR PURIFIER:
WARNING:
Follow the instructions in this manual to reduce the risk of electric shock, short circuit, and/or fire.
SAFETY INSTRUCTIONS
Read and save these instructions.
Thank you for purchasing a Winix air purifier. This product is for household use only.
• The product warranty is printed on the back of this guide This product is
manufactured for use only in Australia. This product is suitable for 220 - 240 V only.
C545(AU) USER MANUAL
AIR PURIFIER
The product uses the "WFM60-SFP201" wireless
module, and the RCM mark could not be added due
to the label size problem of the "WFM60-SFP201"
wireless module, so the RCM mark was added to the
user manual of the finished product.
2610-0307-04 Rev.00
FREQUENTLY ASKED QUESTIONS
Problem Check / Actions to take
It does not turn
on at all.
Is the plug securely attached to
the outlet?
• Make sure the outlet has
power going to it, and ensure
the plug is secured.
Is there a power outage?
• Check to see if other lights
and electrical equipment are
working and try again.
It doesn’t work
in Auto Mode.
Has Auto Mode been selected?
• Press the Mode button until
Auto Mode is selected.
It vibrates and
makes a lot of
noise.
Is it running on a slanted or
uneven surface?
• Move the unit to a hard, flat,
even area of the floor.
The power plug
and outlet feel
hot.
Is the plug securely plugged in?
• Make sure the plug is properly
plugged into the outlet.
Problem Check / Actions to take
There is a
strange smell.
Is it being used in a place with a
lot of smoke, dust, or odours?
• Clean the air intakes on either
side and clean the Pre-Filter.
• Clean or change the filter.
The fan strength
is weak. The unit
is not purifying
the air.
Is the Check Filter indicator
light on?
• Change the filters as required.
The display
panel is dim.
Is the Light Sensor blocked by
debris?
• When Auto Mode is on,
Sleep Mode is automatically
activated when the Light
Sensor detects that the room
is dark.
PRODUCT WARRANTY
Product Name Air Purifier
Model Name C545(AU)
Purchase Date
Warranty period Two (2) Years
Place of purchase
Place of purchase Tel.
Customer
Address
Name
Tel.
After purchase, be sure to complete all of the above information.
Cleaning and user maintenance shall not be
made by children without supervision.
Before cleaning or maintaining, ensure unit is
unplugged.
The cord can become damaged by forcefully
bending, pulling, twisting, bundling, pinching or
placing heavy objects on it.
Do not install in any sort of motor or transport
vehicle (trucks, boats, ships, etc.).
Do not place in an area with excessive amounts
of noxious gases.
Do not place near any flammable materials
(aerosols, fuel, gases, etc.).
Do not place in excessively humid areas where
the unit may become wet.
Do not place unit closer than 30 cm from the wall
during operation. It may cause condensation on
the wall and the surrounding area.
Do not use around mist or fumes from industrial
oil or around large quantities of metallic dust.
Do not place below any electrical outlet.
Do not have the unit facing into wind or drafts.
Do not pull on the power cord when unplugging
the unit.
Do not tie or knot the power cord when unit is in
operation.
If the unit becomes submerged in water, unplug
it and contact customer service.
Do not unplug or move the unit while in
operation.
Do not plug additional appliances into the same
outlet or power supply.
Do not touch the plug with wet hands.
Unplug the unit when not in operation for
extended periods of time.
Do not place around heating elements.

Produkt Specifikationer

Mærke: Ausclimate
Kategori: Luftrenser
Model: C545

Har du brug for hjælp?

Hvis du har brug for hjælp til Ausclimate C545 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Luftrenser Ausclimate Manualer

Ausclimate

Ausclimate C545 Manual

12 August 2025
Ausclimate

Ausclimate ACD245 Manual

30 Juli 2025
Ausclimate

Ausclimate ACD200 Manual

30 Juli 2025
Ausclimate

Ausclimate ACD220SG Manual

30 Maj 2025
Ausclimate

Ausclimate ACD225 Manual

30 Maj 2025

Luftrenser Manualer

Nyeste Luftrenser Manualer

Philips

Philips AC2221 Manual

12 August 2025
Ivation

Ivation IVADGOZHEPA Manual

12 August 2025
Venta

Venta AP100 Hybrid Manual

12 August 2025
Fellowes

Fellowes AeraMax Pro AM3R PC Manual

12 August 2025
Ivation

Ivation IVAOZ85 Manual

12 August 2025
Ivation

Ivation IVAOZC400 Manual

12 August 2025
Ecozy

Ecozy AP-HA500A Manual

12 August 2025
Honeywell

Honeywell HPA-249 Manual

12 August 2025
Daikin

Daikin MC80ZBFVM Manual

11 August 2025
Daikin

Daikin MCK70ZBFVMH Manual

11 August 2025
