Side 1/10

AVALLON.COM

Thank you for purchasing your panel ready undercounter wine or beverage refrigerator from Avallon. Our brand set out with one parcular

goal: To present appliances that are as reliable and recognizable as they are aainable. We create products that invite enre kitchens to be

built around them, serving as an establishing feature in the very spaces they occupy.

In accordance with our ongoing mission to provide cung-edge and forward-thinking products to our loyal customers, we recently

introduced a line of panel ready appliances. These models are fully customizable, and in just a few short steps, you can match your

undercounter refrigerator with your adjacent cabinetry.

This document serves as a guide for installing custom door panels on any of these models. For more product informaon, including owner's

manuals, dimension guides, and more, visit Avallon.com.

P R O D U C T I N F O R M AT I O N

PA N E L I N S TA L L AT I O N I N S T R U C T I O N S

O V E R L AY PA N E L I N S TA L L AT I O N I N S T R U C T I O N S

T O O L S R EQ U I R E D

• Phillips Screwdriver • Drill and 7/64" Drill Bit • #6 Wood Screws* • Clamps (Recommended)

I M P O R TA N T

Warning: The weight of the overlay panel should not exceed 15 lbs.

N O T E

*Because the sizes of overlay panels vary, hardware for mounng your overlay is not included with your Avallon panel

ready refrigerator. #6 wood screws are recommended. The required length depends on the thickness of your overlay

panel. Take care to ensure the screws are not too long to avoid them protruding though the overlay panel.

1. Open the door to a 90° angle.

2. Use a Phillips screwdriver to remove the two (2) screws from the top hinge.

3. Remove the door by carefully sliding the top of the door forward while liing the door up and out of the boom hinge assembly.

AVALLON.COM

4. Lay the door on a solid surface with the glass panel or door front facing downward. We recommend placing the door on a moving

blanket, sheet of cardboard, or other so material before proceeding.

5. Peel away and remove the door gasket from the inside of the door frame as shown below. We recommend starng at one corner and

gently pulling to avoid tearing the gasket. Set the gasket aside in a safe locaon.

6. Place the door (with the glass panel or door front facing downward) on top of the overlay panel as shown below. Align the top edge of

the overlay panel with the top edge of the door frame. We recommend clamping the two pieces together before proceeding to prevent

movement and misalignment.

Door Overlay

Avallon Door

7. Drill pilot holes into your overlay panel using the screw hole openings in the Avallon door for exact placement.

8. Use #6 wood screws of the correct length to secure the overlay panel to the door. The length of screw depends on the thickness of your

overlay panel. Take care to ensure the screws are not too long to avoid them protruding though the overlay panel.

9. Your Avallon refrigerator comes with a standard towel bar handle. If you choose to install this handle, do so using the designated holes in

the door. Hole posioning is shown on the Screw Placement diagrams on the following pages.

10. Replace the door gasket by lining the backside of the gasket up with the track in the top of the door. Press the gasket into the track when

properly aligned and work the gasket into the track all the way around the door.

11. Reinstall the door by placing the lower hinge pin into the lower hinge assembly then securing the two (2) Phillips screws to the upper

hinge axis.
