Side 1/54

ENGLISH DEUTSCH

ITALIANO

ESPAÑOL

INSTALLATION GUIDE

FRAN

AIS

日本語

AXIS T8123 High PoE Midspan 1-port

AXIS T8126 High PoE Splitter 12V

AXIS T8128 High PoE Splitter 24V

Safety information (for AXIS High PoE

Midspan only)

Installation and removal of the AXIS High PoE

Midspan must be carried out by qualified

personnel only.

• AC Power Cable Set:

• The power cable must have regulatory agency

approval for the specific country in which it is used

(for example, UL, CSA, VDE).

• The power cable must be a three-conductor type

(two current carrying conductors; one ground

conductor) terminated on one end by an IEC 60320

appliance coupler (for connection to the AXIS High

PoE Midspan), and on the other end by a plug

containing a ground (earthing) contact.

• The power cable must be rated for a minimum of

250Vac RMS operation, with a minimum rated

current capacity of 5 amps (or a minimum wire

gauge of 18 AWG (0.75mm

• Note: AXIS High PoE Midspans installed in Australia

require power cables with a minimum wire gauge of

16 AWG (1.0 mm

• The AC wall socket-outlet must be near the AXIS High

PoE Midspan and easily accessible. You can remove AC

power from the AXIS High PoE Midspan by

disconnecting the AC power cable from either the wall

socket-outlet or the AXIS High PoE Midspan appliance

coupler.

• The AXIS High PoE Midspan data and data/power

interfaces are qualified as SELV (Safety Extra-Low

Voltage) circuits according to IEC 60950. These

interfaces can only be connected to SELV interfaces on

other equipment.

WARNING!

• Read the installation instructions before connecting

the AXIS High PoE Midspan to its power source.

• Follow basic electricity safety measures whenever

connecting the AXIS High PoE Midspan to its power

source.

• A voltage mismatch can cause equipment damage

and may pose a fire hazard. If the voltage indicated

on the label is different from the power outlet

voltage, do not connect the AXIS High PoE Midspan

to this power outlet.

• This product relies on the building installation for

short-circuit (over current) protection. Ensure that a

fuse or circuit breaker no larger than 120 VAC, 3A.

U.S. (240 VAC, 1.5A international) is used on the

phase conductor.

• The AXIS High PoE Midspan "Data In" and "Data &

Power Out" ports are shielded RJ-45 data sockets.

They cannot be used as Plain Old Telephone Service

(POTS) telephone sockets. Only RJ-45 data

connectors may be connected to these sockets.

Notice:

In keeping with its policy to improve products, as new

technology, components, software, and firmware

become available, Axis reserves the right to change

specifications without prior notice.

Technical support (for AXIS High PoE Midspan

and Splitters)

Should you require technical assistance, please contact

your Axis reseller. If your questions cannot be answered

immediately, the reseller will forward your queries

through the appropriate channels to ensure rapid

response. If you are connected to the Internet, you can:

• Download user documentation

• Find answers to resolved problems in the FAQ database

• Search by product, category, or phrases

• Report problems to Axis support by logging in to your

private support area

• Visit Axis Support at www.axis.com/techsup/

Electromagnetic Compatibility (EMC)

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is

no guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interference to

radio or television reception, which can be determined

by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or

more of the following measures: Re-orient or relocate

the receiving antenna. Increase the separation between

the equipment and receiver. Connect the equipment to

an outlet on a different circuit to the receiver. Consult

your dealer or an experienced radio/TV technician for

help. Shielded (STP) network cables must be used with

this unit to ensure compliance with EMC standards.

USA - This equipment has been tested and found to

comply with the limits for a Class B computing device

pursuant to Subpart B of Part 15 of FCC rules, which are

designed to provide reasonable protection against such

interference when operated in a commercial

environment. Operation of this equipment in a

residential area is likely to cause interference, in which

case the user at his/her own expense will be required to

take whatever measures may be required to correct the

interference.

Canada - This Class B digital apparatus complies with

Canadian ICES-003.

Europe - This digital equipment fulfills the

requirements for radiated emission according to limit B

of EN55022, and the requirements for immunity

according to EN55024 residential and commercial

industry.

Japan - This is a class B product based on the standard

of the Voluntary Control Council for Interference from

Information Technology Equipment (VCCI). If this is used

near a radio or television receiver in a domestic

environment, it may cause radio interference. Install and

use the equipment according to the instruction manual.

Australia - This electronic device meets the

requirements of the Radio communications

Produkt Specifikationer

Mærke:	Axis
Kategori:	Netværkskort/adapter
Model:	T8123 HIGH
Vægt:	350 g
Opbevaringstemperatur (T-T):	0 - 95 °C
Ethernet LAN-porte (RJ-45):	2
Driftstemperatur (T-T):	-10 - 45 °C
Frekvens for vekselstrømsadapter:	50/60 Hz
Dimensioner (BxDxH):	51.3 x 87.9 x 166 mm
Certificering:	FCC Part 15, Class B with FTP cabling\nEN 55022 Class B (Emissions), EN 55024 (Immunity), VCC1\nSafety: CB, UL/cUL per EN 60950-1, GS Mark per EN 60950-1, \nKCC, UL-AR\n
Kabelteknologi:	Shielded category 5 (or higher)
LED-indikatorer:	Ja
Indgangsspænding:	100 - 240 V
Indgangsfrekvens:	50 - 60 Hz
Power over Ethernet (PoE) spænding:	55 V
