Side 1/16
HP
OPERATION
SAFETY
SERVICE
WARRANTY
CONTACT
SPECIFICATIONS
TROUBLESHOOTING
Instruction Manual
READ AND SAVE
THESE INSTRUCTIONS
VP-20
AIR MOVER HIGH VELOCITY FAN
IDEAL FOR
DRYING KITCHEN & BATHROOM FLOORS
DRYING WET SURFACES
DRYING HARD-TO-REACH CRAWL SPACES
HOME PLUMBING PROJECTS
CIRCULATING AIR
COOLING WORK SPACES
STACKABLE
5 UNITS
POWERFUL 10 FOOT
CORD
LIGHT &
COMPACT
3 SPEEDS
3 ANGLES
LOW
AMPS
DAISY
CHAINABLE
SAFETY
CERTIFIED
YEAR
WARRANTY
Introduction
The evolution of the centrifugal air mover continues. With maximum amperage
of 2.1 amps on its highest setting combined with its small size, the Vent VP-20
takes concept of drying surfaces and succeeds in making a true drying partner
for the homeowner. The rotomolded housing is durable, washable and
light enough to carry to any corner of the house (10.8 lbs).
The multipurpose design allows operating positions for horizontal, 45° and
90° angles.
The balanced handle also acts as an optimum cord wrap assembly
freeing the VP-20 of obstructions for secure stacking (5 units).
90° Angle 45° Angle Horizontal
BALANCED CARRYING HANDLE WITH CORD WRAP
PRIVATE LABEL AREA (OPTIONAL)
INTAKE GRILL
3 SPEED POWER SWITCH
2 ADDITIONAL DAISY CHAINABLE OUTLETS
EXHAUST OUTLET
SAFETY
CERTIFIED
YEAR
WARRANTY
GROUND
PLUG
ROTO
MOLDED
IMPACT
RESISTANT
DAISY
CHAINABLE
OPERATIONAL
POSITIONS
0º 45º 90º
B-AIR.COM
B-AIR.COM
Safety Information
When using this equipment basic precautions must be followed, not limited to the
following:
• All units must be supervised while in use.
• Do not put fingers or other objects in the unit while in operation and/or plugged in.
• To avoid electric shock, do not operate the unit in pooled water.
• The motor must be kept dry at all times. If the unit becomes wet, thoroughly dry it
before the next operation.
• Use only a grounded plug for extension cord to avoid risk of electric shock or fire.
• Never use a cord showing any kind of damage or wear.
• Make sure the power source is sufficient to meet the requirements of the air
mover.
• To prevent the unit from overheating, keep all air intake vents clear at all times.
• Clogging or blocking the air intake vents could result in a fire or electrical hazard.
• Do not remove any screens or safety guards from the unit.
• Do not operate the unit close to any dangerous areas, such as explosive gas,
flammables, heaters and unventilated environments.
• Do not use after-market speed control devices.
• Do not use unit if showing damage.
• Before cleaning or servicing, unplug the unit.
• Unplug unit when not in use.
• Do not allow children to play with or near the unit.
• Do not sit or stand on the unit.
• Do not operate unit in stacked position.
• Make sure that hands are dry before handling the unit or power cord.
• Only a qualified electrician should attempt to repair/replace any electrical
components.
• Do not operate any fan with damaged cord or plug. Discard fan or return to an
authorized service facility for examination and/or repair.
• Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
similar coverings.
Do not route cord under furniture or appliances. Arrange cord away from traffic
area where it will not be tripped over.
• Unplug or disconnect the unit from the power supply before servicing.
WARNING! To reduce the risk of fire or electric shock, do not use this fan with a
solid- state speed control device.
Power Requirements - CORDS
• Use 3 pronged adapters that are UL and CE approved and with Ground Fault Circuit
Interrupter (G.F.C.I.).
• Do not use cords that show any kind of wear or damage.
• Cords are not covered by warranty.
WARNING! The Total amperage of the Vent VP-20 Air Mover plus all other
devices plugged into the receptacle must not exceed 12 amps.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Motor Not Running a) Switch is OFF
b) Bad Outlet
c) Faulty Switch/Cord
a) Turn Switch ON
b) Check Outlet / Change to
Another Outlet
c) Faulty Switch/Cord
Motor Not Running a) Fan Blade Loose a) Call Factory for
Replacement Advice
12 13
1
2
3
4
5
6
7
9
10
11
8
14
SPECIFICATIONS
Motor 1/5 HP
Amps H 1.7 AMPS
Built in Power Outlet 9.5 AMPS
Speeds 3 / Positions 3: 0º, 45º, 90º
Certification C-ETL-US
Voltage 115 V
Cycle 60 HZ
Max Static Pressure 160 PA
Daisy Chain Yes / Stackable 5 units
Product Weight 10.8 Lbs
Boxed Weight 12.3 Lbs
Product Size (HxWxD) 13” x 11” x 11.4” / Boxed Size (HxWxD) 13.4” x 11.4” x 11.8”
Wheel Speed (RPM) L1090 / M1320 / H1570
Attached Cord 10’ (FT) 14 AWG
Available Colors Blue
B-AIR.COM
