BT8569

Motorised Height Adjustable

FLOOR-TO-WALL STAND

INSTALLATION GUIDE

SPECIFICATIONS

www.btechavmounts.com

B-TECH AV mounts

• Recommended for screens from 55" - 86" (140cm - 218cm)

• Max load: 100kg (220lbs)

• Suitable for displays with VESA® & non-VESA xings

up to 1000 x 600mm

• Motorised height adjustment range: 650mm (25.59")

• Features easy to use control panel and automatic

safety stop function

• Includes front cover and cable management for a

neat & tidy installation

• Stand dimensions:

1220mm - 1870mm x 1070mm x 256.5 - 272mm H. W. D.

( 48" - 73.62" x 42.13" x 10.10" - 10.71")H. W. D.

INSTALLATION SAFETY INSTRUCTIONS

CAUTION:

Do not attempt to install this product until all instructions and warnings have been read and properly understood.

Please keep these instructions for future reference.

Please check carefully to make sure there are no missing or defective parts - defective parts must never be used.

B-Tech AV Mounts, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure

to observe these safety instructions. In such cases, all guarantees will expire.

General

B-Tech AV Mounts recommends that a professional AV installer or other suitably qualied pers

on install this product. Great care must always

be taken during installation as most AV equipment is of a fragile nature, possibly heavy and easily damaged if dropped. If you do not fully

understand the instructions or are not sure how to install this product safely, then please consult a professional for advice and/or to install this

product for you. Failure to mount this product correctly may cause serious injury or death both during installation and at any time thereafter.

Do not mount any AV equipment that exceeds the specic weight limit of the product you are installing. This weight limit w

ill be clearly

stated on each product and its packaging and will vary from product to product.

Product location

Fixing hardware

It is highly recommended that all xing screws be used where supplied and that the purpose of all other xing hardwareis fully understood.

In some cases more AV equipment xing hardware will be supplied to accommodate dierent models of equipment and set up congurations.

The installer must be satised that any supplied xing hardware is suitable for each specic installation.If any xing screws or included

hardware are deemed not sucient for a safe installation then please con

sult a professional or your local hardware store.

Hazard limitation

When routing cables take advantage of any built in cable management features that the product might provide and ensure that all cables are tidy and secure.

Check to see that any moving aspect of the product can do so unhindered by any cabling. Some products have moving parts and the potential to cause

injury through the crushing or trapping of ngers or other body parts.

Particular attention to the nature of moving parts is required especially when

assembling installing and adjusting during set up.

Immediately after installation double-check that the work done is safe and secure. Double-check all

necessary xings are present and are of ample tightness. It is recommended that periodic inspections of the product and its xing points are made as

frequently as possible to ensure that safety is maintained. If in doubt consult a professional AV installer or other suitably qualied person.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision

This mount is intended for use only with the maximum weights

indicated. Use with equipment heavier than the maximum indicated may result in

instability causing possible injury.

Please pay careful attention to where this product is located, some locations are not suitable for installation. For indoor use only.

Warning: The trolley can tip over which may lead to serious injury. Only adults should push this trolley, do not allow children under 16 to move the trolley.

Push the trolley on the narrow side, never pull the trolley. Do not push at the top of the trolley, push near the middle. Move the trolley slowly. Always

park on level ground, never leave the trolley on an incline. Apply the brakes when the trolley is stationary, release the brakes when pushing the trolley.

Install stand on level ground. When verifying the stability of the structure, consider the following external factors: The strength of the oor, exposure to

sudden and severe wind and danger arising from contact with people and / or objects (eg installations in passageways, emergency exits), if located in a

public or frequently populated area ensure that the product is out of the immediate reach of people.

CONTENTS

Installation Safety Notes......................................................................................................................

Parts List....................................................................................................................................................

Installation Instructions.......................................................................................................................

Operating Console System...............................................................................................................

Product Dimensions............................................................................................................................

B-Tech Contact Details.......................................................................................................................

DANGER: To reduce the risk of an electric shock always:

• Turn o power at source before cleaning.

• Do not use near water or outdoors.

WARNING: To reduce the risk of burns, re, electric shock, or injury to persons:

• Unplug from outlet before putting on or taking o parts.

• Protect any cables or cords being used near this equipment from being walked on or pinched.

• Clean only with a dry cloth and always unplug any electrical items being used in conjunction with this product before cleaning.

• Never operate this mounting system if it has a damaged cord or plug, if it is not working properly, if it has been dropped

or damaged, or dropped into water. Return the mounting system to a service centre for examination and repair.

• Keep the cord away from heated surfaces.

• Never drop or insert any object into any opening.

• Do not operate where aerosol (spray) products are being used or where oxygen is being administered.

• To disconnect, turn all controls to the o position, then remove plug from outlet.

WARNING: Use this mounting system only for its intended use as described in these instructions.

Do not use attachments not recommended by the manufacturer.

WARNING: Never operate the product if it is damaged in any way, liquid has been spilled or objects have

fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped. Contact the original installer/manufacturer to arrange repair or return.

NOTE: BT8568 has no user serviceable parts.

NOTE: BT8568 can support screen sizes up to a maximum of 86 inches (diagonal).

CAUTION: Changes or modications to this unit not expressly approved by the manufacturer can void the units

CE certications and make the unit illegal to operate.

Produkt Specifikationer

Mærke:	B-Tech
Kategori:	Vægophæng
Model:	BT8569
Bredde:	1070 mm
Dybde:	272 mm
Højde:	1870 mm
Produktfarve:	Sort
Monteringstype:	Gulv
Nem at installere:	Ja
Harmoniseret systemkode (HS):	94039010
Højdejustering:	Ja
Maksimal vægtkapacitet:	100 kg
Maksimal skærmstørrelse kompatibilitet:	86 "
Antal understøttede skærme:	1
Minimal skærmstørrelse kompatibilitet:	55 "
Montering interface kompatibilitet (min.):	- mm
Montering interface kompatibilitet (maks.):	1000 x 600 mm
Motoriseret:	Ja
