1500mm

59.06in

600mm

23.62in

1200mm

47.24in

1000mm

39.37in

182mm

7.17in

164.9mm

6.49in

8.2mm

0.32in

164.9mm

6.49in

82mm

3.23in

10.4mm

0.41in

705mm

27.76in

(Including End Cap)

Closed

113.8mm - 128.8mm

4.48in - 5.07in

(Tolerance +/- 1mm)

62mm

2.44in

6mm

0.24in

51.5mm

2.03in

Open

266.8mm - 281.8mm

10.5in - 11.1in

(Tolerance +/- 1mm)

1 0.5

406mm

15.98in

500mm

19.69in

100mm

3.94in

500mm

19.69in

406mm

15.98in

8.5mm

0.33in

300mm

11.81in

300mm

11.81in

600mm

23.62in

8.5mm

0.33in

ISOMETRIC VIEW

B-Tech International Design & Manufacturing Limited

Soft-Open Full Service Portrait Wall Mount for XXL Displays

BT9925

R00

B-Tech No:

Title:

Revision:

The information contained in this drawing is the sole property of B-Tech International Design and Manufacturing Limited, any reproduction in part or whole without the written permission of B-Tech International Design and Manufacturing Limited is prohibited.

Sheet:

1 of 1

File Name: BTD-BT9925

Date:

03/07/2023

1:10

Scale:

Size:

Part of the B-Tech International Group

UNLESS

OTHERWISE

SPECIFIED

DIMENSIONS ARE

IN MILLIMETERS
