Made in China | INS-1705012-A-Mount McKinley-ENG 08/24/23
For the most up to date assembly manual,
to register your set, or to order replacement parts please visit
www.backyarddiscovery.com
SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT
YOU NEED TO ORDER REPLACEMENT PARTS.
Model # 1705012
Mt. McKinley
Owner's Manual & Assembly Instructions
MANUFACTURED BY:
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
800-856-4445
average 2 person assembly time
assembly time may vary based on skill level
Wooden Swing Set
Para obtener instrucciones en español, visite www.backyarddiscovery.com. Pour des instructions en français, visitez www.backyarddiscovery.com.
Important Assembly Notes
1) While assembling unit, take time before and after each phase to make sure fort is level. If fort is
not level, assembly will be dicult and improper assembly may result. Extra care must be taken to
ensure the fort is square.
2) Tighten bolts securely, tighten nuts on bolts ush to the tube or member.
3) Pay close attention to the ITEMS NEEDED FOR EACH PHASE. They can be a valuable aid when
sorting your wood and hardware. Assembly will be made easier if items are sorted by phase.
4) Pay close attention to make sure you are using the correct hardware in the correct phases. Using
incorrect hardware may result in improper assembly.
5) Whenever a T-nut is used, follow these directions. Place T-nut in pre-drilled hole. Tap in with hammer.
Place bolt with washers in the opposite side. Hand tighten to make sure the bolt is in the T-nut.
DO NOT over tighten.
6) Read the steps of each phase thoroughly. The written steps may include important information not
shown in the illustrations.
Basic Setup Dimensions
Place the set on level ground, not less than 6 ft [2 m] from any structure or obstruction such
as a fence, garage, house, overhanging branches, laundry lines, or electrical wires.
Safe Play Zone
Safe play height: 15'-11" [4.8 m]
Maximum fall height: 6'-4 1/2" [1.9 m]
General Information:
Your set has been designed and engineered
for children only and for residential use only.
A maximum of 150 lbs. per child is
recommended for play activities designed for
individual use.
A maximum of 120 lbs. per child is
recommended for play activities designed for
multiple child use.
A maximum of 9 children is recommended for
this swing set.
6'-0"
6'-0"
15'-6" O.A.
12'-6"
O.A.
6'-4"
MAX. FALL
HEIGHT
9'-11" O.A
