Bauknecht TRAK 6465 Manual

Bauknecht Tørretumblere TRAK 6465

Læs gratis den danske manual til Bauknecht TRAK 6465 (2 sider) i kategorien Tørretumblere. Denne vejledning er vurderet som hjælpsom af 20 personer og har en gennemsnitlig bedømmelse på 4.1 stjerner ud af 10.5 anmeldelser. Har du et spørgsmål om Bauknecht TRAK 6465, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

5019 407 00416

Very

Wet

Load

Wet

Load

Fabric Drying

Cycles

& Drying

levels

Drying options

Buzzer & Anti-Crease

cannot be selected

together

Gentle

Reduces drying

intensity

(recommended

for delicate

items)

Dryness

Adjustment

(Adjusts

Dryness Level

according to

wishes)

Buzzer Signals/

Sounds end of

drying cycle at

Intervals

Anti-Crease

Prevents

laundry from

creasing

Start Delay

Delays the

drying cycle

start

Indicative

drying

times

(in minutes)

85’

120’

70’

100’

3.0

5.0

Cotton

max 5 kg

Ready to wear

65’

90’

50’

75’

3.0

5.0

Cupboard dry *

55’

75’

40’

65’

3.0

5.0

Iron dry *

20’

35’

15’

30’

1.0

2.5

Mixed Fabrics

max 2.5 kg

Cupboard dry *

15’

30’

10’

25’

1.0

2.5

Iron dry

60’45’2.5

Extra care

max 2.5 kg

Low drying intensity for

delicates and garments

labelled .

- -

- - -

Airing

Laundry is aired and refreshed

for 30 minutes without

heating.

- -

- - -

Completes drying or dries

single items (suitable for all

fabrics).

- -

QUICK REFERENCE GUIDE

Please also carefully read the

“Instructions for Use”.

TRAK 6465

Cotton

Mixed Fabrics

Extra

care

AiringTime

* Test programmes according IEC 61121.

Start

Pause

Starts the drying cycle. The Start/

Pause indicator lamp is blinking

during the selection phase.

Press to confirm the final selection.

Programme

selection

Turn the programme selector knob to the

desired programme. The indicator next to

the programme name lights up. The start

indicator blinks to show, that the dryer is

in selection mode. After the Start / Pause

button is pressed the start indicator lamp

lights up and the programme starts.

Start delay

Delays the drying cycle start from 1

up to 12 hours.

To select the start delay turn the

programme selector knob to the desired

programme, select the desired options

and press the start delay button. With

each touch of the start delay button,

drying cycle start is delayed by one hour.

Press the Start/Pause button to confirm

your final selection. Start delay indicator

blinks and the count-down is running by

reducing the time in one hour steps. The

count-down is indicated by the blinking of

the start-delay indicator located above the

button. During count-down the drum will

turn from time to time to redistribute the

laundry. The pump may be heard working

for a short time.

To cancel or to change the previously set

time turn programme selector knob to “0”

or open the door.

Remaining time

indication

After cycle start a default drying time is

indicated depending on the selected

drying programme and the dryness

adjustment. After 15 seconds the time will

be adjusted to the real expected

remaining time, depending on size, type

and humidity of the load.

Dryness

Adjustment

Dryness adjustment is an option to adjust

the dryness of the laundry according to

your wishes. Select the desired

programme and the option dryness level

adjustment by pressing the button “

“ for

more dry or the button “

–

“ for more

humid. The selected dryness will be stored

as a pre-setting to the selected drying

programme. Using the drying programme

next time the pre-setting appears. By

pressing the dryness adjustment buttons

‘+’ or ‘–‘ the pre-setting can be changed.

Filter

The indicator lamp lights up when the

filter needs cleaning.

Clean the filter at

the end of every cycle.

PROGRAMME SEQUENCE INDICATION

The programme sequence is indicated by lamps, switching

on when programme step starts and and switching off

when the programme step is passed.

Start

Pauze

5019 407 00416

1. Check that all fastenings are closed and

that pockets are empty.

2. Turn the articles inside out.

3. Place laundry loosely in the drum to make

sure it doesn’t become tangled.

Sort laundry as follows:

A) By care symbols

(on the collar or inside seam):

Suitable for tumble drying

Tumble drying with reduced

drying intensity only. Press gentle

button or select specific

programme

Do not tumble dry

B) By amount and thickness/weight

Whenever the load to be dried exceeds

dryer capacity, separate laundry

according to weight (e.g. towels from

thin underwear).

C) By type of fabrics

Cotton/linen

: towels, cotton jersey, bed

and table linen made of cotton or linen.

Synthetics/Easy Care

: blouses, shirts,

overalls, etc. made of polyester or

polyamide, as well as cotton/synthetic

mixes.

D) By drying level

•Sort into: iron dry, cupboard dry, etc.

Do not tumble dry:

woollens, silk, nylon

stockings, delicate embroidery, fabrics with

metallic decorations, bulky items such as

sleeping bags, etc.

Important: only use specific indicated

dryer-safe additives

and rinse items

that have been treated with stain remover

thoroughly in plenty of water before

drying.

Only use specific indicated

dryer-safe plastic items

and

never

dry

rubber or articles contaminated with

vegetable oil in the dryer

(Option only available when

Programme is selected).

Push the button to turn the drum light on for

30 sec. and push again to turn the drum light

o.

Programme and Options:

•To select a programme, turn the

programme selector knob. The Start/Pause

indicator lamp is blinking, indicating that

the cycle needs to be started.

•To select an option, press the

corresponding button. The indicator

lamp above the button confirms that a

selection has been made.

•Press the button again to cancel the

option.

1. Having selected the desired programme

and options, press the Start button.

If the laundry is not removed at the end

of the drying cycle, an automatic anti-

crease cycle will operate for maximum 60

min. The drum rotates at regular

intervals, preventing the laundry from

creasing.

Anti-Crease protection re-distributes

laundry in the drum.

When the Anti-Crease option is selected

and laundry has not been taken out, an

anti-crease cycle is activated for 12 hrs.

2. On completion of the programme, set the

programme selector knob to position

“0”

When changing the programme during

the drying cycle, the dryer stops. The Start/

Pause indicator lamp is blinking.

To operate the new programme, press the

Start/Pause button again.

To interrupt the dryer during

operation

1. Set the programme selector knob to

Airing.

2. Press the Start button.

Wait at least 5 minutes before opening

the door to allow the dryer to cool

down.

For your safety the programme stops

automatically if you open the door.

3. To restart, after door opening, close the

door and press the Start/Pause button

again.

Clean the lint filter at the end of every

drying cycle:

1. Open the door.

2. Pull the filter upwards.

3. Remove lint using a soft brush or your

fingertips.

4. Push the filter back into place.

If a fault occurs, before contacting our After-

Sales Service, make the following checks to

try and remedy the problem:

Drying takes too long / laundry is not

dry enough:

•Was the correct programme selected?

•Was the inserted laundry too wet (Washing

machine spin speed less than 800 rpm)?

•Is the lint filter dirty (filter indicator lamp on)?

The dryer does not operate:

(after a power failure and/or

interruption to the mains supply,

always press the Start button).

•Is the plug properly inserted into the

mains electricity socket?

•Is there a power failure?

•Has the fuse blown?

•Is the door well closed?

•Has the programme been selected?

•Has the start-delay option been selected?

•Are the END and Anti-crease indicator

lamps lighting up? The drying cycle is

complete and the laundry can be taken

out.

•Has the

Start/Pause

button been pressed?

Lint filter indicator lamp on:

•Is the lint filter clean?

•Is the vent hose blocked?

All programme sequence indicators

blinking:

•Service call necessary.

Replacing the drum light bulb (if

supplied):

•If the inside lamp does not work, the bulb

may be faulty.

•Unplug the dryer.

•Open the door and unscrew the glass

cover insie the drum.

•Replace the faulty bulb with a new one

and screw the glass cover back on.

•Replacement bulb: Philips 15W, 230/240V, E14.

If, after carrying out the above checks the

malfunction persists or appears again, turn

the dryer off and call our After-Sales Service

(refer to guarantee).

Please specify:

•The nature of the fault.

•The dryer type and model.

•The service code (the number after the

word Service on the adhesive rating

plate) on the right-hand side when the

door is open.

•Your full address and phone number.

PREPARING THE LAUNDRY

DRUM LIGHT OPTION

SELECTING A PROGRAMME & OPTIONS

STARTING & COMPLETING A

PROGRAMME

CHANGING A PROGRAMME

INTERRUPTING A PROGRAMME

DAILY MAINTENANCE & CLEANING

TROUBLESHOOTING GUIDE

AFTER-SALES SERVICE

Produkt Specifikationer

Mærke:	Bauknecht
Kategori:	Tørretumblere
Model:	TRAK 6465
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	600 mm
Dybde:	546 mm
Højde:	855 mm
Vægt:	31000 g
Produktfarve:	Hvid
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Tilsluttet belastning:	2800 W
Støjniveau:	65 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	6 kg
Vendbare døre:	Ja
Energiforbrug:	4.02 kWh
