Quick Start Guide

SYSTEM 100

182 SEQUENCER

Legendary Analog Sequencer

Module for Eurorack

Controls

(1) CH-1/CH-2 SEQUENCER COLUMNS – Use the knobs to

set the control voltage output for each step. Each column

sends out control voltages over a dedicated output

jack (CV OUT-1 and CV OUT-2). In PARALLEL mode,

two independent voltages can be set for each step for a

total of up to 8 steps. In SERIES mode, you can program

sequences of up to 16 steps.

(2) TEMPO – This knob controls the step speed of the

sequencer. The internal tempo clock can also be controlled

via the TEMPO CV IN jack. You can also route control

voltages from the CV OUT-1 or CV OUT-2 output jacks

back into the clock via the TEMPO CV IN jack to program

variable timing between each step.

(3) DELAY – Use this knob to set the amount of time taken

(0 to 10 seconds) to shift to the sequence’s next step

voltage, which is set by the 16 knobs in the CH-1/CH-2

SEQUENCER COLUMNS. The DELAY parameter creates

an e ect similar to a portamento e ect, except with an

exponential response. The DELAY function only operates

on the CV OUT-1 output jack (in both PARALLEL and SERIES

modes). The CV OUT-2 output jack is una ected by the

DELAY control.

(4) GATE TIME – This knob controls the length of time

the GATE OUT control voltage is active – known as the

“duty cycle” – in a range from 10% to 90%.

(5) STEP NUMBER – Rotate this knob to set the number of

steps counted before the sequencer re-starts. In PARALLEL

mode, the STEP NUMBER setting a ects both columns

simultaneously. In SERIES mode, the STEP NUMBER setting

a ects only the CH-2 row so that you may create longer

sequences of 9 to 16 steps.

(6) STEP (REPEAT/SINGLE) – This sliding switch determines

how the sequencer responds to triggering. In the REPEAT

setting, the sequence repeats every time it reaches the

end. The SINGLE setting stops the sequence after one full

cycle. The middle STEP setting advances the sequence one

step each time a trigger control voltage is received a the

TRIG IN jack.

(7) START/STOP – Press this button to trigger or stop

the sequence.

(8) PARALLEL/SERIES – This sliding switching determines

whether each step of the CH-1 and CH-2 columns trigger

separately and simultaneously (PARALLEL) for sequences

of up 8 steps, or if the two columns trigger one after the

other (SERIES) with the CH-1 column triggering  rst,

followed by the CH-2 column. In SERIES mode, you can

create sequences of 8 to 16 steps.

(9) CV OUT-1/CV OUT-2 – These jacks send out separate

control voltage signals for the CH-1 (CV OUT-1 jack)

and CH-2 (CV OUT-2 jack) columns. When in SERIES mode,

CV OUT-1 provides the 16-step output and the CV OUT-2

jack provides an 8-step output.

(10) TEMPO CV IN – This jack routes in a control voltage signal

to control the tempo clock.

(11) GATE OUT – This jack sends out a gate trigger signal for

every sequencer step via cables with 3.5 mm connectors.

(12) TRIG IN – This input allows you to route in a trigger

voltage via cables with 3.5 mm connectors.

(13) TRIG OUT – Use this jack to send out a trigger voltage

signal for use with other modules. This trigger voltage is

generated when the sequencer reaches its end step.

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

(9)

(10)

(11)

(12)

(13)

V 1.0

Power Connection

The 182 ANALOG SEQUENCER module comes with the required

power cable for connecting to a standard Eurorack power supply

system. Follow these steps to connect power to the module. It

is easier to make these connections before the module has been

mounted into a rack case.

1. Turn the power supply or rack case power o and

disconnect the power cable.

2. Insert the 16-pin connector on the power cable into the

socket on the power supply or rack case. The connector has

a tab that will align with the gap in the socket, so it cannot

be inserted incorrectly. If the power supply does not have

a keyed socket, be sure to orient pin 1 (-12 V) with the red

stripe on the cable.

3. Insert the 10-pin connector into the socket on the back of

the module. The connector has a tab that will align with the

socket for correct orientation.

4. After both ends of the power cable have been securely

attached, you may mount the module in a case and turn on

the power supply.

Installation

The necessary screws are included with the module for mounting

in a Eurorack case. Connect the power cable before mounting.

Depending on the rack case, there may be a series of  xed holes

spaced 2 HP apart along the length of the case, or a track that

allows individual threaded plates to slide along the length

of the case. The free-moving threaded plates allow precise

positioning of the module, but each plate should be positioned in

the approximate relation to the mounting holes in your module

before attaching the screws.

Hold the module against the Eurorack rails so that each of the

mounting holes are aligned with a threaded rail or threaded

plate. Attach the screws part way to start, which will allow small

adjustments to the positioning while you get them all aligned. After

the  nal position has been established, tighten the screws down.

Speci cations

Inputs

Tempo CV input

Type 3.5 mm TS jack, DC coupled

Impedance 100 kΩ, unbalanced

Max input level +10 V

CV scaling 1 V/oct.

Trigger input

Type 3.5 mm TS jack, DC coupled

Impedance 30 kΩ, unbalanced

Max input level +10 V

Outputs

CV output

Type 2 x 3.5 mm TS jacks, DC coupled

Impedance 600 Ω, unbalanced

Max output level +5 V

Gate output

Type 3.5 mm TS jack, DC coupled

Impedance 600 Ω, unbalanced

Max output level +5 V

Trigger output

Type 3.5 mm TS jack, DC coupled

Impedance 3 kΩ, unbalanced

Max output level +5 V

Controls

Step CV level 0 V to +5 V

Tempo 0.14 Hz to 33 Hz

Delay 0 to 10 s

Gate time 10 % to 90 % duty cycle

Step number 1 to 8 steps

Step switch Repeat / manual / single

Start/stop switch Momentary

Parallel/series switch 8 step / 16 step

Power

Power supply Eurorack

Current draw 30 mA (+12 V), 30 mA (-12 V)

Physical

Dimensions 43 x 81 x 129 mm (1.7 x 3.2 x 5.1")

Rack units 16 HP

Weight 0.17 kg (0.37 lbs)
