Side 1/8
GB
-1-
Chart
START
DELAY
option
MULTI
ZONE
option
POWER
CLEAN
option
ON/OFF
BUTTON
PROGRAMME
SELECTION
BUTTON
(see “Table of
programmes”
below).
START BUTTON
The indicator lights up during operation, flashes when a fault occurs,
and goes off at the end of the programme.
START BUTTON RESET FUNCTION:
Press this button for at least 2 seconds; the selected programme and options will be
cancelled. Main failure displays (repeated flashing of the START indicator lamp) can be
cancelled by RESETTING. Detailed instructions are given in chapter “What to do if...”.
(see at right for options description)
1) Programme data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional options) and may vary
depending on conditions. Differences of up to 20 minutes are possible with sensor programmes as a result of the appliance’s automatic calibration system.
2) Reference programme for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the
EN/Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.
3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.
Table of programmes
Deter-
gent
Consumption
P
Programmes
Available
options
Loading instructions
Litres kWh
Minutes
1)
1
Aqua Steam 40-70°C
Delay
Multizone
Power Clean
Normally or heavily soiled crockery,
including pots and pans. Thanks to
steam action, soaking or hand
pretreatment is no longer needed. In
addition hygiene is ensured due to
the high temperature steam.
X 7-15 0.99-1.75 65-205
2
Pre-Wash cold
Delay
Multizone
Crockery to be washed later. — 4.0 0.03 14
3
Glasses 40°C
Delay
Multizone
Light soiling, for example glasses
and cups.
X 10.0 0.85 100
4
Quickwash 45°C
Delay
Multizone
Lightly soiled crockery, with no
dried-on food.
*
Not recommended tablets
use.
X
*
11.0 0.80 30
5
Eco
2)
50°C
Delay
Multizone
Power Clean
Normally soiled crockery.
Energy-saving programme.
X 11.0 1.05 170
6
Antibacterial
3)
Delay
Multizone
Power Clean
Normally or heavily soiled
crockery, with additional
antibacterial wash. Programme
interruption (e.g. due to door
opening) can compromise
elimination of germs.
X 13.0 1.50 115
7
Overnight 55°C
Delay
Multizone
Normally soiled crockery, gentle
and quiet thanks to the lower spray
pressure (39dbA).
X 13.0 1.20 290
DELAYED START
BUTTON
Press the button
(repeatedly) to delay the
start of the programme.
Adjustable from 1 to 24
hours. With each press of
the button, the delayed
start indicator increases by
one hour and after 24
restarts from 00. Then
press the START button.
The dishwasher will start
after the set time.
5019 396 01822ADG 8930
MULTIZONE
Allows you to choose the
washing zones. Press this
button to select the wash
zones (the display shows
the corresponding symbol):
both racks
(off - no symbols)
only upper rack
only lower rack
POWER CLEAN
Thanks to the additional
power jets this option
provides a more intensive
and powerful wash in the
lower rack, in the specific
area.This option is
recommended for washing
pots and casseroles (see
page 4). Press this button
to activate Power Clean
(the display shows the
corresponding symbol).
RINSE AID INDICATOR
When lit, the rinse aid dispenser
needs to be refilled.
SALT INDICATOR
When lit, the salt reservoir
needs to be refilled.
FAULT INDICATION AND WASH TIME DISPLAY
In normal operation it indicates the remaining time
(h:mm), whereas with “Delayed start” selected it indicates
the time remaining until programme start (hh).
If “F..” appears on the display, see chapter “What to do if...”.
Options and display description
BEFORE USING THE APPLIANCE FOR THE
FIRST TIME CAREFULLY READ THIS QUICK
REFERENCE GUIDE AND THE ASSEMBLY
INSTRUCTIONS! THE GUARANTEE IS NOT
APPLICABLE IF FAULTS ARE CAUSED BY
INCORRECT USE OF THE APPLIANCE.
PROGRAMME SEQUENCE
INDICATOR
Prewash Washing Drying
Quick reference guide
