Side 1/8

GB -1-

Chart

PROGRAMS SELECTION

BUTTON

Push “P” button (repeatedly)

until selected program number

is shown on the display

(P1...Px) - see “Table of

programs” below.

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the

program.

When the door is opened during a washing cycle,

the cycle is temporarily paused: the Start indicator

blinks. To resume the cycle close the door and

push Start button again.

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute

(0:01 is shown into the display).

If pressed when the dishwasher is switched off,

it drains any possible liquids from dishwasher

(1 minute process).

(see at right for options description)

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional options) and may vary

depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the appliance’s automatic calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the

EN/Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.

3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.

Table of programs

Deter-

gent

Consumption

Drying

Phase

Programs

Available

options

Loading instructions

Litres kWh

Minutes

Sensor 40°-70°C

Delay

Antibacterial

rinse

Recommended program for routine

washes, with dried-on food

(e.g. EN 50242).

X 7-14 1.00-1.60 70-155 Full

Pre-Wash cold

Delay Crockery to be washed later. — 4.0 0.03 14 NO

Rapid 45°C

Delay

Lightly soiled crockery, with no dried-

on food.

X 11.0 0.80 30 NO

Eco

50°C

Delay

Antibacterial

rinse

Normally soiled crockery.

Energy-saving program.

X 12.0 1.03 170 Full

Fast Daily 60°C

Delay

Antibacterial

rinse

Normally to heavily soiled crockery. X 10.0 1.30 80 Full

Steam

Delay

Antibacterial

rinse

Program including steam action

dedicated for heavily soiled crockery,

pots and pans. Soaking or hand

pretreatment is no longer needed.

X 14.0 1.70 180 Full

5019 396 03626

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS

QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

Options and display description

SALT INDICATOR

When lit (at the end of the cycle),

the salt reservoir needs to be

refilled.

RINSE AID INDICATOR

When lit (at the end of the cycle),

the rinse aid dispenser needs to

be refilled.

WASH TIME DISPLAY

Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates

the time remaining until program start (h.00) - below 1h (0:min).

If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY

BUTTON EXCEPT CANCEL/OFF BUTTON.

FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES

AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.

DELAYED START BUTTON

Push the button

(repeatedly) to delay the

start of the program –

delay indicator turns on.

Adjustable from 1 to 24

hours. With each press

of the button, the delay

increases by one hour and

after "h 24" returns to

"h 00”. When this option

is selected the delay

indicator turns on. Then

press the START button.

The dishwasher will start

after the set time.

ANTIBACTERIAL RINSE

This function activates an

antibacterial rinse at the end of

the wash cycle, guaranteeing a

further reduction of bacteria.

Press the button to activate

or deactivate the function.

This function can be used with

the programs indicated in

the table of programs.

The dishwasher door must

be kept shut for the entire

duration of the program in

order to guarantee reduction

of bacteria. If the door is

opened the indicator lamp

starts flashing.

TABLET SETTING

This setting allows to

optimize the cycle

performances according the

type of detergent used.

Push the Tablet button for

3 seconds (until the indicator

lights up) if you are using the

combined detergents in

tablet (rinse aid, salt and

detergent in 1 dose). If you

are using powder detergent

or liquid detergent, the

Tablet indicator on the

control panel has to be off.

Quick reference guide

Whirlpool is a registered trademark of Whirlpool USA
