BeSafe iZi Modular A RF X1 i-Size Manual

BeSafe Bilsæde iZi Modular A RF X1 i-Size

Læs gratis den danske manual til BeSafe iZi Modular A RF X1 i-Size (93 sider) i kategorien Bilsæde. Denne vejledning er vurderet som hjælpsom af 15 personer og har en gennemsnitlig bedømmelse på 5.0 stjerner ud af 8 anmeldelser. Har du et spørgsmål om BeSafe iZi Modular A RF X1 i-Size, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/93
a
g
c
b
j
i
e
f
h
2
31
4
5
6
7
8 9
10
11
12
16 17
18
1
2
3
4
5
6
321
<2 yrs
>2 yrs
SIP+
> 25 cm
1
13
2
3
d
19
14 15
click!
click!
101
107
113
118
124
130
136
142
148
153
158
163
167
171
177
189
1
14
19
24
29
36
42
48
54
60
66
72
78
84
89
95
USER MANUAL
Rear facing: 61-105 cm
Forward facing: 88-105 cm
Max. weight: 18 kg
Rear & forward facing
Age approx.: 6 m - 4 yrs
UN regulation no. R129 i-Size
iZi Modular A
i-Size
8 9
! Vital information
• The child seat MUST NOT be installed in a front passenger
seat WITH AN ACTIVATED AIRBAG.
• iZi Modular can only be installed on the iZi Modular
i-Size base.
• iZi Modular is approved rearfacing for children with a stature
height from 61 to 105 cm, with a maximum weight up to 18 kg and
forward facing for children with a stature height from 88 to 105 cm
with a maximum weight up to 18 kg.
• iZi Modular RF is approved rearfacing for children with a stature
height from 61 to 105 cm, with a max. weight up to 18 kg.
• Important: Do not use forward facing before the child is over 15
months. (Not applicable for iZi Modular RF versions)
• BeSafe recommends to use the seat for as long as possible in the
rearfacing position.
• The harness straps must always be locked when the child is in
the seat.
• The harness straps must be tightened without slack and
not twisted.
• This seat contains belt retractors; always assure that the harness
is tight by accessing the shoulder belts inside the shoulder pads
and pulling the shoulder belts upwards.
• The shoulder pads contain magnets. Magnets can influence
electronic equipment such as pacemakers.
• Protect any part of the child’s body which is exposed to the sun.
• Always dress your child in a thin layer of clothes to avoid direct
contact between harness belts and skin. Avoid puy clothes since
this prevents being able to tighten the belts fully.
• We recommend that this seat is used only for children who can sit
upright, usually not younger than 6 months.
• Remove the extra seat cushion when the child is over 2 years.
• Remove the extra side supports when the child is over 2 years
or earlier when the child does not fit between these side
supports anymore.
• When the child weighs over 18 kg or the shoulder height exceeds
above the highest position of the shoulder straps, the child must
change to a seat suitable for children with a weight above 18 kg.
• Replace the seat if it has been in a collision where the speed was
10 km/h and above or if there is a suspicion that the seat can be
damaged for whatever reason. Although it may look undamaged,
if you were to have another accident, the seat may not be able to
protect your child to the level to which it was designed.
• Prevent the seat from becoming trapped or weighed down by
luggage, seats and/or slamming doors.
• Make sure you can fit no more than one finger between the harness
and your child (1 cm).
• DO NOT attempt to dismantle, modify or add any part to the seat.
Warranty will be void if non-original parts or accessories are used.
• Never leave your child unattended in the seat.
• Make sure all passengers are informed about how to release your
child in case of emergency.
• Make sure luggage or other objects are properly secured. Unsecured
luggage may cause severe injuries to children and adults in case
of accidents.
• Never use the seat without the cover. The cover is a safety feature
and may only be replaced by an original BeSafe cover.
• Do not use any aggressive cleaning products; these may harm the
construction material of the seat.
• When washing the seat cover, make sure to follow the wash label on
the inside of the cover.
• BeSafe advises that child seats should not be bought or sold
second-hand.
• KEEP this user manual for later use with the seat.
• DO NOT use the seat for longer than 7 years. Due to ageing, the
quality of the material may change.
• DO NOT use at home. It has not been designed for home use and can
only be used in a vehicle.
• When the child seat is mounted in the car check all the areas where
the child seat might touch the interior. We recommend using a
(BeSafe) protection cover in these places to avoid cuts, marks or
discolouration to the interior of the vehicle, especially in vehicles
with leather or wooden interiors.
• If in doubt, consult either the car seat manufacturer or the retailer.
a
g
c
b
j
i
e
f
h
2
31
4
5
6
7
8 9
10
11
12
16 17
18
1
2
3
4
5
6
321
<2 yrs
>2 yrs
SIP+
> 25 cm
1
13
2
3
d
19
14 15
click!
click!
Thank you for choosing BeSafe iZi Modular A (RF)
! It is important that you read this user manual BEFORE
installing your seat. Incorrect installation could endanger
your child.

Produkt Specifikationer

Mærke: BeSafe
Kategori: Bilsæde
Model: iZi Modular A RF X1 i-Size
