Side 1/3

CRANK

MANIVELLE

MANIVELA

FOOTREST (NO STEP)

REPOSE-PIED (PAS UN MARCHEPIED)

DESCANSO PARA LOS PIES (NO ESCALON)

FOLDING LEGS

PIEDS ESCAMOTABLES

PATAS PLEGABLES

SNAP-IN KNOBS

BOUTONS À ENCLENCHER

MANGOS DE LA MANIVELA

FRONT VISE JAW

MÂCHOIRE AVANT

MORDAZA FRONTAL

REAR JAW

MÂCHOIRE ARRIÈRE

MORDAZA TRASERA

RELEASE LEVER

LEVIER DE DÉCLENCHEMENT

PALANCA DE LIBERACIÓN

Workmate®225 Type 5

Cat. No. WM225 Type 5 Form No. 630670-00 Feb. ‘05

MPORTANT SAFETY INSTRUCTIONS

1. Do not load with more than 450 pounds.

2. Do not apply an unbalanced load which could cause the work center to tip over.

3. Do not use the work center as a stepladder or standing platform. Do not use the lower

platform as a step when the work center is in “Workbench” position. The footboard is a

foot REST only.

4. Do not store work center outdoors or in a damp location.

5. Avoid applying excessive force when clamping with the swivel pegs.

6. Be sure that the legs are fully open (for workbench height) and be sure that the table

locks in position.

7. When using a power tool with the work center, follow the safety instructions in the

tool’s instruction manual.

8. Always wear safety glasses when operating power tools.

9. An even pressure of the vise jaws on the workpiece is essential. Tighten both crank

handles uniformly.

SAVE THIS MANUAL FOR FUTURE REFERENCE

TO REDUCE RISK OF INJURY:

• Before any use, be sure everyone using this tool reads and understands all safety

instructions and other information contained in this manual.

• Save these instructions and review frequently prior to use and in instructing others.

READ ALL INSTRUCTIONS

ASSEMBLY:

The Workmate® 225 Type 5 work center comes partially assembled. A standard hammer

is required for assembly. A plastic socket wrench is included. Empty the contents of the

box and identify all components . Place the frame on the floor in the(see Figure 1) (A)

position shown in . Find the release levers near the front rubber feet on theFigure 1

sides of the frame. Depress both release levers as shown in and pull up untilFigure 2

you hear the frame lock in place.

VISE JAW BRACKET:

1. Select the vise screws (D) and the pivot nuts . Screw one pivot nut onto each(E)

vise screw about halfway as shown in , assemble washer on vise screw.Figure 3 (P)

2. Insert the unthreaded end of the vise screws into the frame such that the pivot nuts

are located in the slots on the top of the frame and the unthreaded ends protrude

through the holes in the front of the frame, as shown in Figures 3 and 4.

3. Install the two vise cranks (F) and secure them by driving the pins through the(N)

holes in the cranks and the vise screws. (Align the holes in the vise cranks with the

holes in the vise screws and strike the pins sharply with a steel hammer until they

are flush with the sides of the vise cranks.) See Figure 5.

4. Closely examine the two front top blocks and the two rear ones. Note that the front

blocks do not have a protruding tab on the bottom side where the rear blocks do.

Select the front vise jaw, (B), and the two front top blocks, . Place the top blocks(K)

on the rails of the frame as shown in Figure 6.

5. Install the front vise jaw on top of the top blocks so that the small holes at each end

of the jaw fit down over the posts on the top side of the blocks. With the jaw

positioned as described above insert into the frame as shown in insert twoFigure 6,

of the four bolts, (M) into the holes in the jaw and tighten them securely into the

holes in the pivot nut. Use the socket wrench, (J) provided, shown in Figure 1.

NOTE: For clarity, only the left side assembly is shown. Perform all operations

on right side as well.

6. Select the rear vise jaw, and the two rear top blocks, . Position the rear top(C) (L)

blocks on the frame rails so that the tab ears in the bottom of the blocks fit into the

key holes of the frame rail. Position the top blocks so their raised posts are toward

the rear of the frame, as shown in . Now install the rear vise jaw so that theFigure 7

small holes in the ends of the jaw fit over the raised posts on the top blocks you just

installed.

7. Insert the remaining two bolts, (M) into the holes in the jaw and through the top

blocks into the raised posts of the vise guides. The holes in the rear blocks are not

threaded so you will feel resistance as you cut threads into them.

WARNING: IMPORTANT SAFETY WARNINGS AND INSTRUCTIONS

INSTRUCTION MANUAL

8. Snap-in crank handle as shown in Figure 8.

9. To assemble the rubber feet to your Workmate: Turn the unit upside down. Swing

out the four legs to the fully extended and locked position. Align the rubber foot with

the leg as shown in . Lightly tap foot into place with a hammer.Figure 9

CHANGING THE INDEXED POSITION OF THE REAR JAW:

1. Install the rear jaw in 1 of 3 possible indexed “keyhole” positions by indexing the rear

vise jaw into a keyhole in the vise jaw bracket. Secure the rear jaw by sliding it to the

back of the keyhole. As shown in Figure 7.

SWIVEL PEGS:

1. The four supplied swivel pegs can be used in any of the holes in the front and rear

jaws. The pegs are used to extend the dimensions of your Workmate’s holding

capacity. (Figure 10)

FIG. 2

FIG. 5

FIG. 4

FIG. 8 FIG. 9

FIG. 10

FIG. 1

FIG. 6 FIG. 7

BEFORE RETURNING THIS PRODUCT

FOR ANY REASON PLEASE CALL

1-800-54-HOW-TO (544-6986)

IF YOU SHOULD EXPERIENCE A PROBLEM

WITH YOUR BLACK & DECKER PRODUCT,

CALL 1-800-54-HOW-TO (544-6986)

BEFORE YOU CALL, HAVE THE FOLLOWING INFORMATION AVAILABLE, CATALOG No.,

TYPE No., AND DATE CODE. IN MOST CASES, A BLACK & DECKER REPRESENTATIVE

CAN RESOLVE YOUR PROBLEM OVER THE PHONE. IF YOU HAVE ASUGGESTION OR

COMMENT, GIVE US A CALL. YOUR FEEDBACK IS VITAL TO BLACK & DECKER.

SERVICE INFORMATION

Black & Decker offers a full network of company-owned and Authorized Service

locations throughout North America. All Black & Decker Service Centers are staffed with

trained personnel to provide customers with efficient and reliable power tool

service. Whether you need technical advice, repair, or genuine factory replacement

parts, contact the Black & Decker service location nearest you. To find your local service

location, refer to the yellow page directory under “Tools—Electric” or call:

1-800-54-HOW-TO.

FULL TWO-YEAR HOME USE WARRANTY

Black & Decker (U.S.) Inc. warrants this product for two years against any defects in

material or workmanship. The defective product will be replaced or repaired at no charge

in either of two ways:

The first, which will result in exchanges only, is to return the product to the retailer from

whom it was purchased (provided that the store is a participating retailer). Returns

FRAME

CADRE

BASTIDOR REAR JAW

MÂCHOIRE ARRIÈRE

MORDAZA TRASERA

FRONT JAW

MÂCHOIRE AVANT

MORDAZA FRONTAL

VISE SCREW

VIS D’ÉTAU

ESPARRAGO

PIVOT NUT

ÉCROU DE PIVOT

TUERCA DE GIRO

VISE CRANK

MANIVELLE D’ÉTAU

MANIVELA DE LA PRENSA G.

CRANK HANDLE

POIGNÉE DE MANIVELLE

ASA DE LA MANIVELA

SWIVEL PEGS

MORDACHES ORIENTABLES

TOPES GIRATORIOS J.

SOCKET WRENCH

CLÉ À DOUILE

DADO

FRONT TOP BLOCKS

CALES SUPÉRIEURES AVANT

BLOQUES DE REMATE FRONTALES L.

REAR TOP BLOCKS

CALES SUPÉRIEURES ARRIÈRE

BLOQUES DE REMATE TRASEROS

BOLTS

BOULONS

TORNILLOS N.

PINS

CHEVILLES

PERNOS

WASHERS

RONDELLES

ARANDELAS

RUBBER FEET

BOUT DE CAOUTCHOUC

REGATONES DE GOMA

FIG. 3

Produkt Specifikationer

Mærke:	Black And Decker
Kategori:	Sav
Model:	WM225
Bredde:	- mm
Dybde:	- mm
Produktfarve:	Træ
Maksimal belastningsvægt:	204.11 kg
Materiale:	Stål
Antal produkter inkluderet:	1 stk
Højde (maks.):	- mm
