FCC CERTIFICATION
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC ID: 2A3BF-RPW001 IC: 21116 -RPW001
If abused or misused, the rechargeable batteries may leak. In extreme
cases, they may even present a risk of explosion, fire, heat, smoke or
gas. Blackstar Amplification Ltd. does not accept any liability for damage
arising from abuse or misuse.
Switch the AIRWIRE i58 off after use.
Only charge the AIRWIRE i58 at ambient temperatures between
10°C/50°F and 40°C/104°F.
When not using the AIRWIRE i58 for extended periods of time,
charge it regularly (about every three months).
Do not damage or dismantle.
Do not heat above 60°C/140°F, e.g. do not expose to sunlight or
throw into a fire.
Do not continue to use AIRWIRE i58 if defective.
Dispose of the AIRWIRE i58 at special collection points.
Store the AIRWIRE i58 in a cool and dry place at room temperature
(approx. 20°C/68°F).
Hereby, Blackstar Amplification Ltd., declares that this type of equipment
is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
For customers in the European Union
If you want to discard electrical and electronic items, please contact
your dealer or supplier for further information. These symbols on the
products, packaging, or on any documents in the package mean it is
incorrect to mix the used electrical and electronic products and batteries
with general household garbage. These symbols are only valid in the EU.
Please contact your local authorities or dealer for more information on
the disposal of old items and used batteries:
To protect our environment, please take old products and used batteries
to proper collection places, and follow your national legislation and the
Directives 2012/19/EU and 2006/66/EC.
Information on Disposal in Countries outside the European Union
To dispose of the
AIRWIRE i58
properly and protect our environment,
please contact your local authorities to get more information on how to
dispose of old products and batteries.
SPECIFICATION:
Operation Frequency: 5.8GHz
Channels: 4 Channels
Transmission Distance: Up to 35 Meters
Latency: <5.95ms
Frequency Response: 20 Hz~20 kHz
Output Impedance: 1KΩ
Connectors: 1/4” TS Connectors
USB jack: DC In 5V USB Type-C
Power: Rechargeable lithium battery
Charging Time: <2.5 hours
Operation Time: 9 Hours when fully charged
Dimensions (mm): 67 x 37.2 x 20.5
Weight: Net 45g (Transmitter or Reciever)
Inside the package: Quick Start Guide, Charging Cable, Carry pouch
TRANSMITTER
RECEIVER
3
4
1 2
5 6
3
5
1 2
6 74
ENG ENG
TRANSMITTER
1.
POWER button:
Powers the unit on/off
2. PAIR button: Pairs the transmitter with the receiver and is used to
select operating channel
3. USB Type C: Used for charging
4. CHANNEL indicators 1-4: For indicating channels and battery status
5. POWER indicator: Indicates when the unit is on and paired
6.
1/4” TS Connector: For connecting to any instrument with a ¼” output
RECEIVER
1.
POWER button:
Powers the unit on/off
2. PAIR button: Pairs the transmitter with the receiver and is used to
select operating channel
3. USB Type C: Used for charging
4. CABLE TONE switch: Used to select CABLE TONE simulation
5. CHANNEL indicators 1-4: For indicating channels and battery status
6. POWER indicator: Indicates when the unit is on and paired
7. 1/4” TS Connector: For connecting to the input jack of an audio
playback device
HOW TO USE:
Hold the POWER buttons for 3 seconds to turn On/Off the
Transmitter and the Receiver.
Press the PAIR buttons to select channels on both the Transmitter and the
Receiver, ensuring both transmitter and receiver channels are the same.
The four CHANNEL indicators (1-4) indicate the selected channel.
The power indicator and the selected channel indicator on the Receiver
will blink slowly when it’s not paired with the Transmitter, and it will stop
blinking when it is paired successfully.
NOTE: If more than one set of AIRWIRE i58s are being used at the
same time, make sure different sets are in different channels.
CABLE TONE: The AIRWIRE i58 offers wireless high-res signal
transfer, so there is no treble loss like using a long cable.
However, the CABLE TONE switch allows the user to emulate the
sound of a long cable by slightly rolling off the higher frequencies
if such an effect is desired.
ENG
The Receiver will automatically shut down after 10 minutes if
unpaired to save battery life.
When fully charged, AIRWIRE i58 can offer up to 9 hours operation
time. The CHANNEL indicators use three colours to indicate the
battery status:
Battery Status Channel Indicator Colour
Full White
75% - 100% Yellow
< 30% Red
< 10% Red blinking rapidly
USING GUITARS WITH ACTIVE PICKUPS
In the event of unwanted noise when AIRWIRE i58 is paired with a guitar
with active pickups, you can reduce the interference by increasing the
distance between the transmitter and the guitar’s circuitry. To do this, use
an extension cable between the guitar’s output jack and the transmitter.
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ THESE INSTRUCTIONS AND KEEP THEM IN A SAFE PLACE
1. Do not perform service operations beyond those described in
the AIRWIRE i58 manual. Service is required when the AIRWIRE i58
has been damaged in any way, such as:
- Liquid has been spilled or objects have fallen into the AIRWIRE i58
- The AIRWIRE i58 has been exposed to rain or moisture
- The AIRWIRE i58 does not operate normally or changes in
performance in a significant way
- The AIRWIRE i58 is dropped or the enclosure is damaged
2. Do not place near heat sources, such as radiators, or appliances that
produce heat.
3. Clean only with a dry cloth.
ENG
WARNING:
Risk of reproductive harm from exposure to Lead
www.P65Warnings.ca.gov
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT REMOVE SCREWS. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THE APPLIANCE TO RAIN OR MOISTURE.
Radio Approvals: FCC Part 15.249, RSS-247(Canada), EN 300 440
(Europe), EN 301.489 (Europe) This device is in compliance with
the essential requirements and other relevant provisions of Directive
2014/53/EU. All essential radio test suites have been carried out.
Detailed DOC file please visit our website: www.blackstaramps.com
IC CAUTION: This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, (2) this device
must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment. This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
ENG
